Wireless LAN User’s Guide
63
Problem
Communication
is disconnected
soon after
connection to
the access point
Possible Cause
Incorrect setting of
IP address
Access control may
be disabled
Possible Solution
Check the network setting. “Setting the network”.
In case of using TCP/IP protocol, you can check IP
address as follows:
1. Click [Start] -> [All programs] -> [Accessories] ->
[Command prompt].
2. In [Command prompt] or [MS-DOS prompt]
window, input [IPCONFIG] command as follows,
then press [Enter] key.
Example: In case of C drive being the hard disk:
C:\ipconfig [Enter]
Check that the IP address is correctly displayed:.
IP Address................: 10.0.1.3
Subnet Mask.............: 255.255.255.0
Default Gateway.........: 10.0.1.1
When IP address is displayed as
[169.254.XXX.YYY] or [0.0.0.0],
IP address is not correctly fetched from the access
point. In that case, restart the computer itself. If the
display is still unchanged, check the setting of
TCP/IP.
If [Cable Disconnected] or [Media Disconnected] is
displayed without showing IP address, check the
setting of network name (SSID) and network key.
Also, set the network authentication according to
the access point.
Check the setting of “Enable network access control
using IEEE 802.1X”.Refer to “Assigning parameters”.
When restricting the access of wireless LAN clients
using IEEE802.1X authentication, put a check mark
on “Enable network access control using IEEE
802.1X”.
When using at home, remove a check mark on
“Enable network access control using IEEE802.1X”.
For the method of setting related with IEEE802.1X
authentication, refer to the access point manual.
Ocampa5 (51-64) 10/12/03, 11:41 AM63
