INDOOR UNIT
FLOOR / CEILING
ABYG14L
VT
A
ABY
A18L
VT
A
Fan motor
102
91
93
97
98
98
93
91
95
95
92
96
92
94
91
Sirocco Fan Assy
9385258006
95
Rubber
9385102002
92
Casing
9358543009
96
Motor Fixing Table
9358591000
94
Fan Motor Assy
9602401017
98
Motor Fixture
9358594001
97
Protector
9359282006
93
Casing Cover
9358544006
Ref.
Description
Part number
2010.10.13
110
112
Table of Contents
Table of Contents
1
Specifications
2
Electrical Data
6
Fan Motor
6
Dimensions
9
Refrigerant System Diagram
21
Pipe Length
22
Additional Charge
22
Circuit Diagram
23
Outdoor Pcb Circuit Diagram
33
Branch Box Pcb Circuit Diagram
39
Indoor Pcb Circuit Diagram
43
Wall Mounted
49
Error Detection
63
Parts (Outdoor Unit)
68
Parts (Branch Box)
72
Parts (Indoor Unit)
75
Accessories
113
