INDOOR UNIT
FLOOR / CEILING
ABYG14L
VT
A
ABYG18L
VT
A
Control unit
103
102
104
105
101
103
106
101
Control Box
9358600054
--
Room Thermistor Assy
9703299087
103
Controller PCB Assy (18)
9707393859
103
Controller PCB Assy (14)
9707393842
102
Control Box Cover Assy
9359097006
105
Terminal 3P
9306489045
106
Terminal 3P
9703345012
9707398274
104
Power Supply PCB Assy
Ref.
Description
Part number
2010.10.29
111
113
Table of Contents
Table of Contents
1
Specifications
2
Electrical Data
6
Fan Motor
6
Dimensions
9
Refrigerant System Diagram
21
Pipe Length
22
Additional Charge
22
Circuit Diagram
23
Outdoor Pcb Circuit Diagram
33
Branch Box Pcb Circuit Diagram
39
Indoor Pcb Circuit Diagram
43
Wall Mounted
49
Error Detection
63
Parts (Outdoor Unit)
68
Parts (Branch Box)
72
Parts (Indoor Unit)
75
Accessories
113
