9.1 PARAMETERS TABLE
8.2 DESCRIPTION OF PARAMETERS
CODE - Access code:
It is necessary when you want to change the configuration parameters. To only visualize
the adjusted parameters it is not necessary to insert this code.
Code 231 - Technician
Code 123 - Advanced
TC.01 - Controller language:
Selects the language for displaying messages on the controller:
PORT = Portuguese;
ESP = Spanish;
ENG = English.
TC.02 - Temperature unit:
Selects the controller temperature unit:
°C = Celsius;
°F = Fahrenheit.
Note: When the unit is changed, the controller goes into pause mode and reconfigures
the parameters for the new unit, restarting the operation soon after.
TC.03 - Type of fluid:
Informs the type of fluid used in the collector. Information used to estimate the amount
of energy absorbed by the solar heating system:
WATE = water;
GLYC = propylene glycol solution.
TC.04 - Estimated pump flow:
Informs the estimated flow rate of the pump. Information used to estimate the amount
of energy absorbed by the solar heating system.
TC.05 - Flow unit (volume):
Defines the desired flow unit to display the estimated energy absorbed by the solar
heating system.
TC.06 - Power unit:
Selects the desired energy unit to display the estimated energy absorbed by the solar
heating system.
9. SETTINGS - ADVANCED LEVEL
Access the settings menu by pressing the SET key for 4 seconds. Then CODE will
appear and then press the SET key again, short press. Use the or keys to enter
the access code value, 123, and when ready press the SET key again (short press). Use
the or keys to select the desired function. With a short press on the SET key it is 11 D
possible to edit its value. Use the or keys to change the value, and when ready,
give a short press on the SET key to memorize the set value and return to the functions
menu. To exit the menu and return to normal operation (temperature display) press the
SET key (long press).
When accessing the adjustment of a parameter, the display will be flashing indicating that
it is SET possible to change the parameter value.
If you have not entered code 123, the adjustment will be locked and when pressing the
1111and keys to change the value of the function, the controller will show the message
Cod X on the display. With the function lock active, when pressing the and keys
to change the function value, the controller will display the message on the
display and it will not be possible to adjust the parameter.
FUN DESCRIPTION MINIMUN MAXIMUN UNIT DEFAULT MINIMUM MAXIMUN UNIT DEFAULT
CODE
Access code
0 9999
-
0 0 9999
-
0
DF.01
Differential (T1-T2) to start the pump
1.0 40.0
°C
8.0 1.0 72.0
°F
14.4
DF.02
Differential (T1-T2) to turn off the pump
1.0 40.0
°C
4.0 1.0 72.0
°F
7.2
DF.03
Minimum T2 (pool/reservoir) superheat temperature setpoint
allowed to the user
-20.0 DF.04
°C
-20.0 -4.0 DF.04
°F
-4.0
DF.04
Maximum superheat temperature setpoint T2 (pool/reservoir)
allowed to the user
DF.03 105.0
°C
105.0 DF.03 221.0
°F
221.0
DF.05
T2 superheat temperature to turn off the pump
DF.03 DF.04
°C
70.0 DF.03 DF.04
°F
158.0
DF.06
T2 superheat temperature hysteresis to restart the pump
0.1 20.0
°C
2.0 0.2 36.0
°F
3.6
DF.07
Antifreeze temperature T1 to start the pump
OFF(-20.0) 10.0
°C
8.0 OFF(-4.0) 50.0
°F
46.4
DF.08
Minimum antifreeze time
OFF(0) 600
seconds
60 OFF(0) 600
seconds
60
DF.09
T1 superheat temperature to turn off the pump
0.0 200.0
°C
70.0 32.0
392.0
°F
158.0
DF.10
Pump on time in manual mode
1 720
minutes
360 1 720
minutes
360
DF.11
Temperature sensor T3 to turn off cooling in Holidays mode
0.0 105.0
°C
50.0 32.0 221.0
°F
122.0
DF.12
Minimum temperature T1 to start the pump - scan mode
0.0 105.0
°C
35.0
32.0
221.0
°F
95.0
DF.13
Pump on time - scan mode
OFF(9) 999
seconds
20 OFF(9) 999
seconds
20
DF.14
Pump off time - scan mode
1 999
minutes
30 1 999
minutes
30
DF.15
Maximum differential (T1-T2) for thermal shock protection
OFF(0.0) 200.0
°C
OFF(0.0) OFF(32.0) 392.0
°F
OFF(32.0)
DF.16
Circulation pump type
STD LIN
-
STD STD LIN
-
STD
DF.17
Setpoint diferencial (T1-T2) (bomba de velocidade variável)
1.0 40.0
°C
10.0 1.0 72.0
°F
18.0
DF.18
Increment rate (variable speed pump)
1.0 20.0
°C
1.0
1.0 36.0
°F
1.8
DF.19
Minimum pump speed (variable speed pump)
30 DF.20
%
30 30 DF.20
%
30
DF.20
Maximum pump speed (variable speed pump)
DF.19 100
%
100 DF.19 100
%
100
DF.21
Pump start time at full speed (variable speed pump)
5 300
seconds
10 5 300
seconds
10
A1.01
Auxiliary 1 operating mode
OFF REF
-
HOT OFF REF
-
HOT
A1.02
Auxiliary 1 reference temperature sensor
S1 S4
-
S3 S1 S4
-
S3
A1.03
Minimum temperature setpoint of auxiliary 1 allowed to the
user
-20.0 A1.04
°C
0.0 -4.0 A1.04
°F
32.0
A1.04
Maximum temperature setpoint of auxiliary 1 allowed to the
user
A1.03 105.0
°C
105.0 A1.03 221.0
°F
221.0
A1.05
Auxiliary 1 temperature setpoint
A1.03 A1.04
°C
45.0 A1.03 A1.04
°F
113.0
A1.06
Auxiliary 1 temperature setpoint Economic
A1.03 A1.04
°C
40.0 A1.03 A1.04
°F
104.0
A1.07
Auxiliary 1 operating hysteresis
0.1 20.0
°C
1.0 0.2 36.0
°F
1.8
A1.08
Auxiliary 1 manual activation time
OFF(0) 9999
minutes
120 OFF(0) 9999
minutes
120
A1.09
Cyclic timer on time / scan time (recirculation)
OFF(0) 9999
seconds
OFF(0) OFF(0) 9999
seconds
OFF(0)
AVANÇADO CELSIUS FAHRENHEIT
