Operation Instructions
2.1 Spooling in, Under Load
NEVER exceed winch’s rated line pull. Power-in the winch strap evenly and tightly on the drum.
NEVER touch winch strap or hook while someone else is at the control switch or during winch-
ing operation.
NEVER overload the motor to stall. If the motor stalls, allow it to cool for 15 minutes, to reduce
the chance of motor burnout.
Do not shock load the winch when spooling. Avoid shock loads when spooling by pulsing the control
switch to take up winch strap slack. Shock loads can momentarily far exceed the winch and strap ratings.
2.2 Overloading / Overheating
This winch is rated for intermittent duty. When the motor approaches stall speed, very rapid heat
buildup occurs which may cause motor damage.
1.5.3 Indicator Light
1. When the remote is turned on it will search for a signal for 1 to 3 seconds. If a signal is found the
blue light will stay on.
2. If the winch is not powered up or you are out of range, the blue light will blink regularly.
1.5.4 Pairing Wireless Remote
1. Ensure that both winch cables are disconnected from the battery, and the remote is turned off.
2. Connect the red terminal from the winch, to the battery.
3. Press and hold the remote’s ON/OFF button until the flashing blue LED light appears.
4. Simultaneously press and hold the LINE IN and the LINE OUT buttons for 5 seconds. Do not
release the buttons yet.
5. While holding the LINE IN & LINE OUT buttons, Connect the black terminal to the battery.
6. Release the LINE IN and LINE OUT buttons.
7. Wait for the remote’s blue LED light to remain steady.
8. Test the remote. If the light remains blinking and/or the remote does not operate, follow the
troubleshooting guide in table 4.
Remote Control Use
Table 4 – Remote Pairing Troubleshooting
FlashMode Reason Solution
1
Blinking
blue light
The remote is
searching for a
signal from the
winch
If the
LED light doesn’t stop blinking after releasing the LINE IN &
LINE
OUT
buttons:
a. The remote was not able to pair.
• Disconnect the black terminal from the battery,
repeat pairing steps 3-7.
2
Steady
blue light
The remote has
successfully
paired to the
winch
If the blue light remains steady, but the remote doesn’t appear to work:
a. Turn the remote off.
b. Wait 30 seconds and turn the remote back on.
c. Test the remote.
• If it still doesn’t work, disconnect the black terminal
from the battery, turn off the remote, and
repeat steps 2-7.
3
Light not
turning ON
Dead battery
If the blue
LED light does not appear after holding the ON/OFF button
for 5 seconds:
a. Remove the remote’s cover.
b. Inspect and replace the battery if necessary.
DO NOT power the hook into the fairlead.
This could cause damage to the fairlead.
WARNING
NOTICE
Horizon Global’s Customer Service 1-800-632-3290
©2021 Horizon Global Americas Inc. • F4088-00 REV D (7871) 08/2021
