GETTING STARTED
I n i t i a l s e t - up
1. Remove the FA2 unit from the packaging and locate hose clamps and wheels.
2. Remove ALL filters and packing materials from cartons and the unit cabinet.
3. Place the unit on its side and install wheels in the bottom plate.
4. Remove plastic wrap from gas/odor filter.
5. Carefully remove perforated cardboard from top and bottom of FA201D filter to expose “Green” media.
6. Place FA201D gas/odor filter into bottom of cabinet (NOTE: Pay attention to direction of airflow arrow).
7. Place FA100 HEPA filter on top of gas/odor filter (NOTE: Pay attention to direction of airflow arrow).
8. Place the FA140B pre-filter on top of the HEPA filter. Remove red cap to help with installation. Replace red
cap before operating the unit.
9. Close and latch the lid.
10. Install air inlet at top, back of unit (screws are pre-threaded into cabinet for shipping).
11. Attach power cord to the power receptacle located on the lower rear of the cabinet.
L o c a t i n g t h e a i r c l e a n e r
Placing the FA2 as close as possible to the pollution source reduces the amount of ducting needed, reduces
back-pressure, lowers power consumption, and improves overall performance. Placement should minimize hose
length and the number of bends. Use capture hoods with high efficiency entry whenever possible. Make sure to allow
top access to the filter compartment. The unit exhausts through the bottom panel make sure to allow for
adequate ventilation.
I n l e t h o s e a t t a c h m e n t
Install the air inlet flange (labeled) to the air inlet port located at the back top of the FA2 cabinet. Secure the port
with the screws provided. Attach the hose to the inlet. Connect the hose to a Fumex suction hood or place as
close as possible to the pollution source.
E l e c t r i c p o w e r
Locate the Fumex nameplate placed on the back of the cabinet to determine the power supply necessary. The
FA2 is factory configured for 90-250/1/50-60 and must only use a 15-Amp fuse. Please contact Fumex LLC. with
any questions/concerns regarding power supply.
Confirm that correct power supply is available.
