GETTING STARTED
I n i t i a l s e t - up
1. Remove the FA5-2 unit from the packaging and locate and open the accessory box.
2. Open the FA5-2 cabinet and remove the protective packaging from the FA501D gas/odor filter(s). Replace
the filter into the cabinet noting the airflow direction arrow should point up.
3. The FA500 HEPA filter and FA540B Pre-filter are preinstalled - simply verify the filters are in position.
4. Close and latch the front door.
L o c a t i n g t h e a i r c l e a n e r
Placing the FA5-2 as close as possible to the pollution source reduces the amount of ducting needed, reduces
back-pressure, lowers power consumption, and improves overall performance. Placement should minimize hose
length and the number of bends. Use capture hoods with high efficiency entry whenever possible. The unit
exhausts through the bottom panel make sure to allow for adequate ventilation.
I n l e t h o s e a t t a c h m e n t
Install the air inlet flange (labeled) to the air inlet port located at the back bottom of the FA5-2 cabinet. Secure the
port with the screws provided. Attach the hose to the inlet. Connect the hose to a Fumex suction hood or place
as close as possible to the pollution source.
E l e c t r i c p o w e r
Locate the Fumex nameplate placed on the back of the cabinet to determine the power supply necessary. The
FA5-2 is factory configured for 90-120/1/50-60 or 220-250/1/50-60 and must only use a 20-Amp Fuse. Please
contact Fumex LLC. with any questions/concerns regarding power supply.
Confirm that correct power supply is available.
