WIRING DIAGRAM < DVD SECTION >
E8G00WID
1-14-2
DVD MECHANISM
DVD MAIN CBA UNIT
TO WIRING DIAGRAM <VCR SECTION>
TO MAIN CBA CL1051 (JW006) TO MAIN CBA CN1601 (JW007)
CN301
1 SP(+)
2 SP(-)
3 GND
4 SL(-) 5 SL(+)
6 TRAY-IN
TRAY-IN
DRIVE CBA
M
SLED MOTOR
M
SPINDLE MOTOR
CN401
PICK UP UNIT
CN201
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20
TS(+) TS(-) FS(-) CD-LD FS(+) GND(DVD-PD) GND(CD-PD) PD-MONI DVD-LD VREF NU GND B DVD-P-ON+5V CD/DVD D A C NU GND(LD)
DETECTOR
FSTS
7 9
11
2 3 6 5 4
CN601
VIDEO-Y(I) 1
I/P-SW 2
ASPECT 3
VODEO-Pr/Cr 4
GND 5 GND 7 GND 9 GND 11 GND 15
VIDEO-Pb/Cb 6
VIDEO-Y(I/P) 8
VIDEO-C 10
DVD-AUDIO(L) 12
DVD-AUDIO-MUTE 13
DVD-AUDIO(R) 14
SPDIF 16
DUBBING-INH 1
EV+1.2V 2 EV+1.2V 3 EV+3.3V 4 EV+3.3V 5 EV+3.3V 6
DVD-P-ON+3.3V 7
DVD-P-ON+5V 8
EV+11V 10 EV+11V 9
GND 11 GND 12 GND 13 GND 14 GND 15 GND 16 GND 17
PWRCON 18
FP-DOUT 19
FP-DIN
20
FP-CLK 21 FP-STB 22
REMOTE-DVD 23
DVD-POWER 24
DVD-OPEN/CLOSE 25
DVD-PLAY 26
DVD-STOP 27
OUTPUT-SELECT 28
