FUNAI D8A-A4110DB - Page 56

1-15-3 E8G00PIN
IC612 ( FIP DRIVER )
Pin
No.
IN/
OUT
Signal
Name
Name Function
1 IN FP-CLK
Clock Input
2 IN FP-STB
Serial Interface Strobe
3 -
NU
Not Used
4 -
NU
Not Used
5 - VSS
GND
6 - VDD
Power Supply
7
OUT
a
Segment Output
8 b
9 c
10 d
11 e
12 f
13 g
14 h
15 - VEE
Pull Down Level
16 OUT i
Segment Output
17
OUT
7G
Grid Output
18 6G
19 5G
20 4G
21 3G
22 2G
23 1G
24 - VDD
Power Supply
25 - VSS
GND
26 IN OSC
Oscillator Input
27 -
NU
Not Used
28 IN FP-DIN
Serial Data Input
