FUNAI DDVR-6830 - Disassembly Flowchart; Disassembly Method; Cabinet Disassembly Instructions

1-6-1 H9903DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and
dress the cables as they were originally.
2. Disassembly Method
Note:
(1): Identification (location) No. of parts in the figures
(2): Name of the part
(3): Figure Number for reference
(4): Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P=Spring, L=Locking Tab, S=Screw,
CN=Connector
*=Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5): Refer to “Reference Notes.”ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
[1] Top Case D1 8(S-1) -
[2]
Front
Assembly
D2 *3(L-1), *3(L-2)
1
1-1
1-2
[3] Top Bracket D2 3(S-2) -
[4]
DVD
Mechanism
Assembly
D3
4(S-3), *CN401,
*CN601
-
[5]
Partition
Plate
D3 (S-4) -
[6]
Power
Supply CBA
D3 2(S-5), CN501 -
[7]
Loader
Holder
D3 2(S-6) -
[8]
DVD Main
CBA Unit
D4
2(S-7), *CN201,
*CN301
2
2-1
2-2
3
[1] Top Case
[2] Front Assembly
[3] Top Bracket
[4] DVD Mechanism Assembly [8] DVD Main CBA Unit
[5] Partition Plate
[7] Loader Holder
[6] Power Supply CBA
[9] VCR Chassis Unit
[10] Deck Assembly
[11] DVD Open/Close CBA
[12] Main CBA
[13] Jack-A CBA
[9]
VCR
Chassis Unit
D5
5(S-8), 2(S-9), (S-10),
(L-3)
-
[10]
Deck
Assembly
D6
Desolder,
2(S-11), (S-12)
4,5
[11]
DVD Open/
Close CBA
D6 Desolder -
[12] Main CBA D6 ---------- -
[13] Jack-A CBA D6 Desolder, 2(S-13) -
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
