FUNAI DDVR-6830 - Mechanical Parts List

20050623 1-18-1 H9903CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
DDVR-6830 A
DPVR-6830 B
Ref. No. Mark Description Part No.
A1X FRONT ASSEMBLY H9901BD 1VM220477
A2 TOP CASE(D5 PAL FTZ) H9700ED 0VM101358
A3 CHASSIS H9900ED 1VM220317
A7 PANEL BOTTOM H9700ED 0VM204530
A10! A RATING LABEL(U) H9903ED or ----------
! A RATING LABEL(D) H9903ED ----------
A10! B RATING LABEL(U) H9904ED or ----------
! B RATING LABEL(D) H9904ED ----------
A14 LABEL SERIAL NO. HE240ED ----------
A14 A BAR CODE LABEL H9903ED ----------
A14 B BARCODE LABEL H9904ED ----------
A21 A WARNING LABEL HG249ED ----------
A22 CHASSIS FOOT H79P9JD 0VM412315
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
1B2 DVD MECHA E6160(FG LESS)
N79F0JVM
N79F0JVM
2B2 TOP BRACKET H9700ED 0VM204531
2B3 RODER HOLDER H9600UD 0VM306676
2B5 SHEILD CYLINDER H9700ED 0VM306780
2B9 CUSHION HC460ED 0VM413251
2B16 TAPE HIMELON H9206JD 0VM413956
2B18 FIBER TOP CASE HC460ED 0VM412906
2B21! LASER CAUTION LABEL H9900ED ----------
2B40 PARTITION PLATE H9700ED 0VM306765
2B54 PLATE GROUND(RCA) H9700ED 0VM306867
2B55 PLATE GROUND(21P) H9700ED 0VM416444
2L011 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L012 SCREW S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L020 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L021 SCREW P-TIGHT 3X12 BIND HEAD+ GBMP3120
2L022 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L041 SCREW P-TIGHT 3X6 BIND HEAD+ GBCP3060
2L051 SCREW P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L071 SCREW P-TIGHT M3X10 WASHER
HEAD+
GCMP3100
2L091 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
L0-9 P-TIGHT SCREW 3X8 BIND + GBMP3080
PACKING
S1 A GIFT BOX CARTON H9903ED 1VM320905
S1 B GIFT BOX CARTON H9904ED 1VM320762
S2 STYROFOAM H9600UD 0VM204474
S3 UNIT BAG E5500UD 0VM411683
S7 21P PAD HC463FD 0VM413384
ACCESSORIES
X1 REMOTE CONTROL UNIT 364/
CZF05DD
NB126ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5795ED 0VM416059
X5 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276
X20A! A OWNERS MANUAL(EN) H9903ED 1VMN20475
X20A! B OWNERS MANUAL(SP) H9904ED 1VMN20416
X20B! A OWNERS MANUAL(GE) H9903ED 1VMN20476
X20B! B OWNERS MANUAL(PR) H9904ED 1VMN20417
X20C! A OWNERS MANUAL(HU) H9903ED 1VMN20477
X20C! B OWNERS MANUAL(EN) H9904ED 1VMN21008
X20D! A OWNERS MANUAL(CZ) H9903ED 1VMN20478
X20D! B OWNERS MANUAL(GE) H9904ED 1VMN21009
X20E! A OWNERS MANUAL(SL) H9903ED 1VMN20479
X20F! A OWNERS MANUAL(PL) H9903ED 1VMN20747
Ref. No. Mark Description Part No.
