FUNAI DDVR-6830 - Electrical Parts List

2050623 1-19-1 H9903EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DVD MAIN CBA UNIT
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
DDVR-6830 A
DPVR-6830 B
Ref. No. Mark Description Part No.
DVD MAIN CBA UNIT N79GDJBP
Ref. No. Mark Description Part No.
A
B
MCV CBA
MCV CBA
Consists of the following:
1VSA11775
1VSA11172
MAIN CBA (MCV-A)
DVD OPEN/CLOSE CBA (MCV-C)
SENSOR CBA
---------
---------
1VSA10047
Ref. No. Mark Description Part No.
MAIN CBA (MCV-A)
Consists of the following:
---------
CAPACITORS
C056 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
ELECTROLYTIC CAP. 47µF/25V M CE1EMASTL470
C057 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C058 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMASSL221
C059 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
C062 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C063 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470
C104 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C107 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C109 CHIP CERAMIC CAP.(1608) CH J
470pF/50V or
CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C112 CHIP CERAMIC CAP.(1608) CH J
470pF/50V or
CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C113 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C114 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C116 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C117 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C118 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C121 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C122 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C123 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C124 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C125 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C126 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C127 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C128 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C133 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C135 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C136 ELECTROLYTIC CAP. 100µF/6.3V M H7 CE0KMASSL101
C251 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C252 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C253 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C254 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C301 CHIP CERAMIC CAP.(1608) B K
0.022µF/50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K
0.022µF/25V
CHD1EK30B223
C302 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C303 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C305 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C306 CHIP CERAMIC CAP.(1608) B K
0.047µF/50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K
0.047µF/25V
CHD1EK30B473
C307 CHIP CERAMIC CAP.(1608) B K
0.022µF/50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K
0.022µF/25V
CHD1EK30B223
C308 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C309 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V or
CHD1JJ3CH680
CHIP CERAMIC CAP. CG J 68pF/50V CHD1JJ3CG680
C310 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V or
CHD1JJ3CH680
