1-6-5 H9903DC
View for A
Rotate this roulette in
the direction of the arrow
A
DVD Mechanism
HOW TO EJECT MANUALLY
1. Remove the Top Case, Front Assembly and Top Bracket.
2. Remove four Screws (S-3) in Fig. D3. Do not disconnect connectors.
3. While lifting up the DVD Mechanism, rotate the roulette in the direction of the arrow as
shown below.
4. Pull the tray slowly manually.
To Next Page
