FUNAI DDVR-6830 - Page 66

2050623 1-19-5 H9903EL
C1535 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1536 ELECTROLYTIC CAP. 22µF/6.3V M or CE0KMASDL220
ELECTROLYTIC CAP. 22µF/6.3V M CE0KMASTL220
C2002 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C2004 ELECTROLYTIC CAP. 100µF/6.3V M H7 CE0KMASSL101
C2012 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
CONNECTORS
CN051 242 SERIES CONNECTOR
224202117W1
J322C17TG001
CN701 AFV PCB ASSEMBLY H9901BD H9901AFV
DIODES
D051 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D052 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D054 ZENER DIODE DZ-10BSBT265 or NDTB00DZ10BS
ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D056 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D057 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D058 ZENER DIODE MTZJT-774.3C QDTC0MTZJ4R3
D101 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D102 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D103 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D104 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D105 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D106 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D107 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D108 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D109 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D110 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D111 ZENER DIODE DZ-5.1BSCT265 or NDTC0DZ5R1BS
ZENER DIODE MTZJT-775.1C QDTC0MTZJ5R1
D115 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D118 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D119 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D121 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D301 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D502 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D503 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D505 LED(RED) 204HD/E NPQZ00204HDE
D510 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D511 ZENER DIODE DZ-7.5BSAT265 or NDTA0DZ7R5BS
ZENER DIODE MTZJT-777.5A QDTA0MTZJ7R5
D512 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
Ref. No. Mark Description Part No.
D555 LED MIE-534A2 or NPZZM1E534A2
LED SIR-563ST3F P or QPQPS1R563ST
LED SIR-563ST3F Q QPQQS1R563ST
D612 PCB JUMPER D0.6-P5.0 JW5.0T
D613 PCB JUMPER D0.6-P5.0 JW5.0T
D701 ZENER DIODE DZ-33BSDT265 or NDTD00DZ33BS
ZENER DIODE MTZJT-7733D QDTD00MTZJ33
D1052 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1053 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1054 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1057 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1301 ZENER DIODE DZ-5.6BSBT265 or NDTB0DZ5R6BS
ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
ICS
IC102 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102
IC301 IC Y/C/A LA71750EM-MPB-E QSZBA0RSY020
IC451 IC HIFI LA72648M-MPB-E QSZBA0RSY033
IC501 SYSCON IC M3776AMCH-AA5GP QSZAB0RHT064
IC502 IC BR24L02F-WE2 or QSZBA0TRM068
IC CAT24WC02WI-TE13 NSZBA0TBG007
IC611 V.F.D. 7-BT-298NYM TVFD150FT014
IC612 VFD DRIVER/CONTROLLER IC
PT6313-S-TP(L) or
NSZBA0TG2007
VFD DRIVER IC SC16313G NSZBA0T0S005
IC751 IC SWITCH TC4053BF(EL N F) or QSZBA0TTS163
IC ANALOG MULTIPLEXER
CD4053BNSR or
NSZBA0TTY093
IC ANALOG MULTIPLEXERS
CD4053BCSJX or
NSZBA0TF3071
IC SWITCH TC4053BF(N) QSMBA0STS002
IC1002 VOLTAGE REGULATOR
PQ1LAX95MSPQ
QSZBA0TSH053
IC1003 VOLTAGE REGULATOR
PQ1LAX95MSPQ
QSZBA0TSH053
IC1201 IC OP AMP KIA4558P/P or NSZBA0SJY035
IC OP AMP RC4580IP or NSZBA0STY173
IC OP AMP UTC4558 NSZBA0S2H001
IC1204 FIBER OPTIC TRANS.MODULE 0C-
0805T*002 or
JWHHA00JD002
OPTICAL TRANSMITTING MODULE
JST1162 or
JWHHA00SLT01
FIBER OPTIC TRANS.MODULE
GP1FA513TZ0F
JWHHA00SH006
IC1403 DRIVER FOR DVD MM1636XWRE QSZBA0TMM108
IC1404 IC SWITCH TC4053BF(EL N F) or QSZBA0TTS163
IC ANALOG MULTIPLEXER
CD4053BNSR or
NSZBA0TTY093
IC ANALOG MULTIPLEXERS
CD4053BCSJX or
NSZBA0TF3071
IC SWITCH TC4053BF(N) QSMBA0STS002
COILS
L053 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L101 A BEAD CORE ASSEMBLY H9900ED 1VSA11420
L101 B BEAD CORE ASSEMBLY H9900ED 1VSA11421
L122 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L251 INDUCTOR 5.6µH-K-26T LLAXKATTU5R6
L302 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L402 INDUCTOR 47µH-K-5FT LLARKBSTU470
L451 INDUCTOR 47µH-K-5FT LLARKBSTU470
L452 PCB JUMPER D0.6-P5.0 JW5.0T
L501 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
Ref. No. Mark Description Part No.
