FUNAI DPVR-4600 - Page 15

1-6-4 H9500DC
[11] Deck
Assembly
(S-12)
(S-12A)
FE Head
Cylinder Assembly
ACE Head
Assembly
[13] DVD OPEN/
CLOSE CBA
[14] Function CBA
[15] Jack CBA
[12] Main CBA
LD-SW
Pin
Hole
Hole
Shaft
Cam Gear
[12] Main CBA
[11] Deck Assembly
[12] Main CBA
SW507
LD-SW
Pin
BOTTOM VIEW
Lead connections of Deck Assembly and Main CBA
Desolder
Desolder
Lead with
blue stripe
Lead with
blue stripe
Desolder
Desolder
From
FE Head
From
Cylinder
Assembly
From
ACE Head
Assembly
Lead with
white stripe
Lead with
blue stripe
From
Capstan
Motor
Assembly
Printing side
Lead with blue stripe
Desolder from bottom
Fig. D8
