FUNAI DRVR-B778 - Page 74

20051207 1-19-4 E9712EL
CHIP CERAMIC CAP. CG J 47pF/ 50V CHD1JJ3CG470
C1588 CHIP CERAMIC CAP.(1608) CH J 47pF/ 50V or CHD1JJ3CH470
CHIP CERAMIC CAP. CG J 47pF/ 50V CHD1JJ3CG470
C1590 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1591 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1592 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1594 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C1595 ELECTROLYTIC CAP. 22µF/ 16V M or CE1CMASDL220
ELECTROLYTIC CAP. 22µF/ 16V M CE1CMASTL220
C1597 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1598 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1599 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C1601 ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMAVSL100
C1602 ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMAVSL100
C1603 ELECTROLYTIC CAP. 1µF/ 50V M H7 CE1JMAVSL1R0
C1604 ELECTROLYTIC CAP. 1µF/ 50V M H7 NP CP1JMAVSB1R0
C1605 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTL471
C1606 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTL471
C1607 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTL471
C1609 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C1610 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1611 ELECTROLYTIC CAP. 47µF/ 6.3V M H7 CE0KMAVSL470
C1612 ELECTROLYTIC CAP. 100µF/ 6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/ 6.3V M CE0KMASTL101
C1617 CHIP CERAMIC CAP.(1608) B K 0.1µF/ 25V or CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/ 16V CHD1CK30B104
C1618 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTL471
C1619 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C1620 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1621 CHIP CERAMIC CAP. CH J 39pF/ 50V or CHD1JJ3CH390
CHIP CERAMIC CAP. CG J 39pF/ 50V CHD1JJ3CG390
C1626 CHIP CERAMIC CAP. F Z 0.22µF/ 16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/ 25V CHD1EZ3FZ224
C1627 CHIP CERAMIC CAP. F Z 0.22µF/ 16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/ 25V CHD1EZ3FZ224
C1628 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C1629 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C1630 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1631 CHIP CERAMIC CAP.(1608) B K 1000pF/ 50V CHD1JK30B102
C1632 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C1633 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C1634 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C1637 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1639 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C1640 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
Ref. No. Description Part No.
C1643 ELECTROLYTIC CAP. 47µF/ 6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/ 6.3V M CE0KMASTL470
C1648 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C1649 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C1652 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C1657 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1658 CHIP CERAMIC CAP.(1608) B K 1000pF/ 50V CHD1JK30B102
C1659 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1660 CHIP CERAMIC CAP.(1608) B K 1000pF/ 50V CHD1JK30B102
C1661 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1662 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1663 CHIP CERAMIC CAP.(1608) B K 0.1µF/ 25V or CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/ 16V CHD1CK30B104
C1664 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1665 CHIP CERAMIC CAP.(1608) B K 1000pF/ 50V CHD1JK30B102
C1671 ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/ 25V M CE1EMASTL4R7
C1672 ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/ 25V M CE1EMASTL4R7
C1673 ELECTROLYTIC CAP. 47µF/ 16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/ 16V M CE1CMASTL470
C1675 ELECTROLYTIC CAP. 47µF/ 25V M or CE1EMASDL470
ELECTROLYTIC CAP. 47µF/ 25V M CE1EMASTL470
C1681 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1684 ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/ 25V M CE1EMASTL4R7
C1685 ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/ 25V M CE1EMASTL4R7
C1686 ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/ 25V M CE1EMASTL4R7
C1687 ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/ 25V M CE1EMASTL4R7
C1688 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1689 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1691 CHIP CERAMIC CAP.(1608) CH J 47pF/ 50V or CHD1JJ3CH470
CHIP CERAMIC CAP. CG J 47pF/ 50V CHD1JJ3CG470
C1692 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTL471
C1693 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTL471
C1694 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1695 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1696 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C1697 ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/ 25V M CE1EMASTL4R7
C1698 ELECTROLYTIC CAP. 4.7µF/ 25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/ 25V M CE1EMASTL4R7
C1699 CHIP CERAMIC CAP.(1608) CH J 47pF/ 50V or CHD1JJ3CH470
CHIP CERAMIC CAP. CG J 47pF/ 50V CHD1JJ3CG470
C1700 CHIP CERAMIC CAP. F Z 1µF/ 10V CHD1AZ30F105
C1701 ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMAVSL100
C1702 ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMAVSL100
CONNECTORS
CN1503 PH CONNECTOR TOP 2P B2B-PH-K-S or J3PHC02JG001
Ref. No. Description Part No.
