FUNAI DRVR-B778 - Page 75

20051207 1-19-5 E9712EL
PH CONNECTOR (WHITE) TOP 2P B2B-PH-K-
S(LF)
J3PHC02JG017
CN1504 242 SERIES CONNECTOR 224202119W1 J322C19TG001
CN1505 FE CONNECTOR TOP 8P 08FE-BT-VK-N JCFEJ08JG001
CN1506 AFV PCB ASSEMBLY E9701AFV E9701AFV
DIODES
D301 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D502 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D503 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D510 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D511 ZENER DIODE DZ-7.5BSAT265 or NDTA0DZ7R5BS
ZENER DIODE MTZJT-777.5A QDTA0MTZJ7R5
D512 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D555 LED MIE-534A2 or NPZZM1E534A2
LED SIR-563ST3F P or QPQPS1R563ST
LED SIR-563ST3F Q QPQQS1R563ST
D1501 DIODE 1N5397-B NDLZ001N5397
D1502 DIODE 1N5397-B NDLZ001N5397
D1504 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1506 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1507 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1508 ZENER DIODE DZ-4.3BSCT265 or NDTC0DZ4R3BS
ZENER DIODE MTZJT-774.3C QDTC0MTZJ4R3
D1511 ZENER DIODE DZ-10BSBT265 or NDTB00DZ10BS
ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D1512 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1513 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1516 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1517 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1518 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D1519 ZENER DIODE DZ-11BSBT265 or NDTB00DZ11BS
ZENER DIODE MTZJT-7711B QDTB00MTZJ11
D1521 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1523 ZENER DIODE DZ-5.6BSBT265 or NDTB0DZ5R6BS
ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1525 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1526 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1528 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1529 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1531 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1532 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1534 ZENER DIODE DZ-33BSDT265 or NDTD00DZ33BS
ZENER DIODE MTZJT-7733D QDTD00MTZJ33
D1535 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1537 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1538 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
Ref. No. Description Part No.
D1539 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1540 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1542 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
ICS
IC301 IC Y/C/A LA71750EM-MPB-E QSZBA0RSY020
IC451 IC HIFI LA72648M-MPB-E QSZBA0RSY033
IC501 SYSCON IC M3776AMCH-AD4GP or QSZAC0RHT068
SYSCON IC M3776AMCH-AD2GP QSZAB0RHT068
IC612 VFD DRIVER IC PT6315(L) NSZBA0RG2009
IC1501 IC(ANALOG SW) CD4052BPWR NSZBA0TTY142
IC1504 VOLTAGE REGULATOR PQ070XF01SZH or QSZBA0SSH054
VOLTAGE REGULATOR PQ070XF01SZ QSZBA0SSH026
IC1505 VOLTAGE REGULATOR PQ070XF01SZH or QSZBA0SSH054
VOLTAGE REGULATOR PQ070XF01SZ QSZBA0SSH026
IC1506 IC OP AMP RC4580IP NSZBA0STY173
IC1507 VIDEO SWITCH MM1697AJBE QSZBA0TMM150
IC1508 IC SWITCH TC4053BF(EL N F) or QSZBA0TTS163
IC SWITCH TC4053BF(N) or QSMBA0STS002
IC ANALOG MULTIPLEXERS
CD4053BCSJX_NL or
NSZBA0TF3138
IC SWITCH BU4053BCF-E2 or QSMDA0TRM010
IC ANALOG MULTIPLEXERS CD4053BCSJX or NSZBA0TF3071
IC ANALOG MULTIPLEXER CD4053BNSR NSZBA0TTY093
IC1509 IC SWITCH TC4053BF(EL N F) or QSZBA0TTS163
IC SWITCH TC4053BF(N) or QSMBA0STS002
IC ANALOG MULTIPLEXERS
CD4053BCSJX_NL or
NSZBA0TF3138
IC SWITCH BU4053BCF-E2 or QSMDA0TRM010
IC ANALOG MULTIPLEXERS CD4053BCSJX or NSZBA0TF3071
IC ANALOG MULTIPLEXER CD4053BNSR NSZBA0TTY093
IC1511 IC VPS/PDC SLICER LC74793JM-TLM-E QSZBA0TSY018
IC1513 IC OP AMP KIA4558P/P or NSZBA0SJY035
IC OP AMP RC4580IP NSZBA0STY173
IC1514 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102
IC1515 DRIVER FOR DVD MM1636XWRE QSZBA0TMM108
IC1518 AV SWITCH MM1443XJBE QSZBA0TMM152
COILS
L251 INDUCTOR 5.6µH- K-26T LLAXKATTU5R6
L302 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L402 INDUCTOR 47µH- K-5FT LLARKBSTU470
L451 INDUCTOR 47µH- K-5FT LLARKBSTU470
L452 PCB JUMPER D0.6-P5.0 JW5.0T
L501 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L502 PCB JUMPER D0.6-P5.0 JW5.0T
L503 INDUCTOR 1.8µH- K-26T LLAXKATTU1R8
L1501 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1503 PCB JUMPER D0.6-P5.0 JW5.0T
L1504 PCB JUMPER D0.6-P5.0 JW5.0T
L1505 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1506 PCB JUMPER D0.6-P5.0 JW5.0T
L1507 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-470K-
841040NP or
LLBD00PKV023
CHOKE COIL 47µH- K or LLBD00PKV007
CHOKE COIL 47µH- K or LLBD00PKV005
CHOKE COIL 47µH- K or LLBD00PKT001
FIXED INDUCTORS LGB0810T-470K LLBD00PU6007
L1508 PCB JUMPER D0.6-P5.0 JW5.0T
L1509 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1510 INDUCTOR 15µH- K-26T LLAXKATTU150
L1513 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47
L1515 BEAD CORE ASSEMBLY E9700ED 1VSA11697
L1517 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q302 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
Ref. No. Description Part No.
