20051207 1-19-13 E9712EL
JUNCTION CBA
REAR JACK CBA
METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZQZ01R3
METAL OXIDE FILM RES. 1W J 1.3 Ω RN01JZPZ01R3
R1020 CARBON RES. 1/6W J 1.8k Ω or RCX6JATZ0182
CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1021 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1022 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R1023 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H0222
CHIP RES. 1/10W F 2.2k Ω RRXAFR5Z0222
R1024 CHIP RES. 1/10W J 68k Ω RRXAJR5Z0683
R1025 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H0562
CHIP RES. 1/10W F 5.6k Ω RRXAFR5Z0562
R1029 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1032 CARBON RES. 1/6W J 2.2k Ω or RCX6JATZ0222
CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1035 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1036 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1037 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103
CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1038 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1039 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1040 CARBON RES. 1/4W J 8.2 Ω RCX4JATZ08R2
R1041 CARBON RES. 1/4W J 5.6 Ω RCX4JATZ05R6
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7ZU001
METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7KE009
METAL OXIDE FILM RES. 1W J 2.7 Ω RN012R7DP003
R1059 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1126 CHIP RES. 1/10W J 33k Ω RRXAJR5Z0333
MISCELLANEOUS
2L019 SCREW S-TIGHT M3X8 BIND HEAD+ or GBMS3080
SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
2B18 HEAT SINK E6800ED 1VM420987
AC1001! AC CORD PE8G2X91H0AA061 WAB0182LW016
F1001! FUSE T1.6AL/250V or PAGC20BW3162
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH1001 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER DFH-001 XH01Z00RP001
FH1002 FUSE HOLDER MSF-015 or XH01Z00LY001
FUSE HOLDER DFH-001 XH01Z00RP001
J01 PCB JUMPER D0.6-P26.0 JW26.0T
J02 PCB JUMPER D0.6-P24.5 JW24.5T
J03 PCB JUMPER D0.6-P5.0 JW5.0T
J04 PCB JUMPER D0.6-P16.0 JW16.0T
J05 PCB JUMPER D0.6-P25.5 JW25.5T
J06 PCB JUMPER D0.6-P24.5 JW24.5T
J07 PCB JUMPER D0.6-P21.0 JW21.0T
J08 PCB JUMPER D0.6-P8.5 JW8.5T
J09 PCB JUMPER D0.6-P15.0 JW15.0T
J10 PCB JUMPER D0.6-P30.0 JW30.0T
J1009 PCB JUMPER D0.6-P5.0 JW5.0T
J1012 PCB JUMPER D0.6-P5.0 JW5.0T
T0011! SWITCHING TRANSFORMER 5727 LTT00EPKT189
Ref. No. Description Part No.
JUNCTION CBA (PSV-B)
Consists of the following:
----------
CONNECTORS
CN051A 242 SERIES CONNECTOR TUC-P19X-B1 WHT
ST or
JCTUB19TG002
CONNECTOR 19P TUC-P19X-B1 JCTUS19TG001
MISCELLANEOUS
JW1001 FLAT CABLE 10P AWG26#2651/P2.0/100 WX1E9700-003
Ref. No. Description Part No.
JW1002 FLAT CABLE 9P AWG26#2651/P2.0/100 WX1E9700-004
Ref. No. Description Part No.
REAR JACK CBA (PSV-C)
Consists of the following:
----------
CAPACITORS
C2003 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C2004 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C2005 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C2006 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C2007 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C2008 CHIP CERAMIC CAP. B K 1000pF/ 50V CHD1JKB0B102
C2009 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTL100
C2010 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C2011 CHIP CERAMIC CAP. B K 1000pF/ 50V CHD1JKB0B102
C2012 ELECTROLYTIC CAP. 1µF/ 50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/ 50V M CE1JMASTL1R0
C2013 CHIP CERAMIC CAP. B K 1000pF/ 50V CHD1JKB0B102
DIODES
D2001 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2002 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2003 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2004 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2005 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2006 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2007 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2008 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2009 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2010 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
COIL
L2001 BEAD CORE ASSEMBLY E9700ED 1VSA11697
TRANSISTORS
Q2002 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) or QQS102SC1815
TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199 NQS40KTC3199
Q2003 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) or QQS102SC1815
TRANSISTOR KTC3199(Y) or NQSY0KTC3199
Ref. No. Description Part No.
