20051207 1-19-14 E9712EL
AFV CBA
TRANSISTOR KTC3199 NQS40KTC3199
Q2004 CHIP TRANSISTOR KTA1504GR-RTK or NQ140KTA1504
CHIP TRANSISTOR KTA1504Y-RTK NQ1Y0KTA1504
Q2005 CHIP TRANSISTOR KTA1504GR-RTK or NQ140KTA1504
CHIP TRANSISTOR KTA1504Y-RTK NQ1Y0KTA1504
RESISTORS
R2003 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2004 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R2005 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2006 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2007 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2008 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2009 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R2010 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R2011 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R2012 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R2013 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R2014 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R2015 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
MISCELLANEOUS
2B60 PLATE GROUND(21PIN) H9500ED 0VM415201C
JK2001 RGB CONNECTOR MRC-021V-03 ABS(B11 or JXGL210LY006
RGB CONNECTOR MRC-021V-03 JXGL210LY003
JW2001 FLAT CABLE 11P AWG26#2651/P2.0/85 WX1E9700-005
JW2002 FLAT CABLE 4P AWG26#2651/P2.0/85 WX1E9700-006
Ref. No. Description Part No.
AFV CBA
Consists of the following:
1VSA11738
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C4 CHIP CERAMIC CAP. CH J 56pF/ 50V or CHD1JJ3CH560
CHIP CERAMIC CAP. CG J 56pF/ 50V CHD1JJ3CG560
C5 CHIP CERAMIC CAP.(1608) CH J 22pF/ 50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/ 50V CHD1JJ3CG220
C6 CHIP CERAMIC CAP. CH J 56pF/ 50V or CHD1JJ3CH560
CHIP CERAMIC CAP. CG J 56pF/ 50V CHD1JJ3CG560
C7 CHIP CERAMIC CAP. CH C 3pF/ 50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/ 50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/ 50V CHD1JD3CH3R0
C8 CHIP CERAMIC CAP. CH C 3pF/ 50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/ 50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/ 50V CHD1JD3CH3R0
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C12 ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMASSL100
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C15 ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMASSL100
C16 ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMASSL100
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C20 ELECTROLYTIC CAP. 3.3µF/ 50V M H7 CE1JMASSL3R3
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/ 50V CHD1JZ3FZ104
C22 ELECTROLYTIC CAP. 10µF/ 16V M H7 CE1CMASSL100
C24 ELECTROLYTIC CAP. 0.22µF/ 50V M H7 CE1JMASSLR22
C27 CERAMIC CAP.(AX) F Z 0.1µF/ 50V CCA1JZTFZ104
Ref. No. Description Part No.
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-
09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
IC
IC1 IC AUDIO PROCESSOR MSP3417G-QG-B8-V3 NSZBA0SP3005
COILS
L1 INDUCTOR 10µH- K-26T LLAXKATTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH- K-26T LLAXKATTU180
L4 INDUCTOR 10µH- K-26T LLAXKATTU100
RESISTORS
R1 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R4 CHIP RES. 1/10W J 120k Ω RRXAJR5Z0124
R5 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R6 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
Ref. No. Description Part No.
