Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
FUNCTION CBA UNIT
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A3AF1MMA-001
Ref. No. Description Parts No.
FUNCTION CBA UNIT A31M0MSW-001
Ref. No. Description Parts No.
POWER SUPPLY CBA
Consists of the following
A3AF0MPW-001
CAPACITORS
C602# SAFTY CAP. 1000pF/250V KX CA2E102MR101
C603# SAFTY CAP. 1000pF/250V KX CA2E102MR101
C604# CAP METALLIZED FILM 0.22µF/275V/K CTA224PKR001
C605 CAP ELE 330µF/200V/M/87 CEB3310S6016
C606 CERAMIC CAP. 820pF/2kV CA3D821PAN04
C607 CHIP CERAMIC CAP. B K 1800pF/50V CHD1JK30B182
C608 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C609 CHIP CERAMIC CAP. B K 0.068µF/50V CHD1JK30B683
C610 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C614# CAP METALLIZED FILM 0.22µF/275V/K CTA224PKR001
C616# SAFTY CAP. 1000pF/250V KX CA2E102MR101
C617# CAP CERAMIC 100pF/250V KX CA2E101MR100
C622 CHIP CERAMIC CAP.(2125) B K 10µF/6.3V CHE0KK30B106
C623 CHIP CERAMIC CAP.(1608) B K 4.7µF/6.3V CHD0KK30B475
C651 CAP ELE 470µF/25V/M/85 CED4710V8006
C652 CAP ELE 470µF/25V/M/85 CED4710V8006
C653 CAP ELE 470µF/25V/M/85 CED4710V8006
C654 CAP ELE 470µF/16V/M/85 CEC4710V8006
C655 CAP ELE 470µF/16V/M/85 CEC4710V8006
C656 CAP ELE 1µF/50V/M/85 CEF1R00V8006
C660 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C663 CAP ELE 100µF/10V/M/85 CEB1010V8006
C665 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C666 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1001 CAP ELE 470µF/25V/M/85 CED4710V8006
C1002 CAP ELE 470µF/25V/M/85 CED4710V8006
C1003 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1004 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1006 CAP ELE 47µF/100V/M/85 CEH4700V8006
C1007 CAP ELE 47µF/100V/M/85 CEH4700V8006
C1009 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1010 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1011 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1012 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1013 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1015 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1016 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1017 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1018 CERAMIC CAP. B K 100pF/1kV CCD3AKN0B101
C1019 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1020 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
CONNECTORS
CN501 FFC CONNECTOR IMSA-9615S-23A-PP-A JC96J23ER007
CN601# CONNECTOR S2P3-VH (LF)(SN) JCVHC02JG002
CN1001 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN)
J3PHC02JG029
DIODES
D601 DIODE 1N5406BH NDL1001N5406
D602 DIODE 1N5406BH NDL1001N5406
D603 DIODE 1N5406BH NDL1001N5406
D604 DIODE 1N5406BH NDL1001N5406
D605 ZENER DIODE MM5Z4V3B ND1BMM5Z4V3B
D607A# ZENER DIODE SMD TFZVTR27B QD1B00TFZV27
D608# DIODE ZENER 1ZB36BB NDWZ0001ZB36
D609A# DIODE SCHOTTKY SMD RB520SM-30 T2R QD1ZRB520SM3
D610 DIODE SWITCHING HSC119 TRF -E QD1Z00HSC119
D621 DIODE SWITCHING HSC119 TRF -E QD1Z00HSC119
D623 ZENER DIODE MM5Z30B ND1B0MM5Z30B
D650 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D651 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D653 DIODE SCHOTTKY SB3A0BH NDWZ000SB3A0
D654# DIODE ZENER 1ZB20BB NDWZ0001ZB20
D655 DIODE SCHOTTKY SB3A0BH NDWZ000SB3A0
D656 DIODE FAST RECOVERY RS1BJTD ND1Z0RS1BJTD
D657 ZENER DIODE MM5Z11B ND1B0MM5Z11B
D660 IC SHUNT REGULATOR SL431A-AT NSZBA0TAUK01
D661 DIODE SWITCHING HSC119 TRF -E QD1Z00HSC119
D662 IC SHUNT REGULATOR SL431A-AT NSZBA0TAUK01
D664 ZENER DIODE SMD TFZVTR4.7B QD1B0TFZV4R7
D1001 DIODE SCHOTTKY SMD SK210TD ND1Z0SK210TD
D1004 DIODE SWITCHING HSC119 TRF -E QD1Z00HSC119
D1005 DIODE SWITCHING HSC119 TRF -E QD1Z00HSC119
D1006 ZENER DIODE SMD TFZVTR30B QD1B00TFZV30
D1007 ZENER DIODE MM5Z11B ND1B0MM5Z11B
ICS
IC602# IC PHOTOCOUPLER TLP781F(D4-FUNBLL F) QPEL781FBLLF
IC1001 IC LED BACKLIGHT CONTROLLER BD9488F-
GE2/SOP/18P
QSCA0T0RM418
COILS
L601# COIL LINE FILTER JLB20154/18MH LLEG0Z0XB022
L602# COIL LINE FILTER JLB20154/18MH LLEG0Z0XB022
L1001 COIL POWER INDUCTORS DIP RP1315BNP-
101M/100µH
LLF1010SF013
Ref. No. Description Parts No.
