FUNAI LF320EM4F - Lcd Panel Assembly; Parts List

2013/1/23 13-1 A3AF1CA.fm
TYPE A
PARTS LIST [32ME303V/F7 (Serial No.: ME1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
LCD PANEL ASSEMBLY
Ref.No. Description Part No.
A3 REAR COVER A3AF0UT 1EM030166
A4 BOTTOM COVER A3AF0UT 1EM030167A
A13 JACK HOLDER A31M0UT 1EM334000
A15# RATING LABEL A3AF1UT ----------
A16 LOGO LABEL A3AF1UT ----------
A17 ENERGY GUIDE LABEL A3AF1UT ----------
AC601# AC CORD UL/CSA/1680/NO/BLACK WAC162LTE002
B17 WALL MOUNT BRACKET A11N0UH 1EM434637
B18 WALL MOUNT COVER A2170UT 1EM332137
B23 WIRE LABEL A3AF0UT ----------
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/
184MM
WX1A3AF0S102
CL3701 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/
130MM
WX1A3AF0S121
CL3801 WIRE ASSEMBLY 4PIN 4PIN/320MM&30MM WX1A3AF0C311
L4 SCREW P-TIGHT M3X8 BIND HEAD+ BLK GBHP3080
L23 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L24 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
SA1 STAND ASSEMBLY A20F0PT 1ESA32345
SP3801 SPEAKER MAGNETIC 8Ω/8W S0310F14 DS08110XQ002
SP3802 SPEAKER MAGNETIC 8Ω/8W S0310F14 DS08110XQ002
SSK1 STAND SCREW KIT A31M0UT(SCREW P-
TIGHT M4X14 BIND HEAD+BLK)
1ESA34004
PACKI NG
S1 CARTON A3AF1UT 1EM440122
S3 STYROFOAM TOP A3AF0UT 1EM030285
S4 STYROFOAM BOTTOM A3AF0UT 1EM030286
S6 SET BAG A31F0UT 2EMC00088
S7 SERIAL NO. LABEL A01PBUH ----------
ACCESSORIES
X1 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579
X2# OWNERS MANUAL A31M1UT 2EMN00089
X3 REMOTE CONTROL UNIT FYT-WI002678 URMT32FNT005
X4 BATTERY DRY R03(SIZE AAA ) XB00M0RKT001
X6 QUICK START GUIDE A31M1UT 1EMN30401
X7 REGISTRATION CARD (MAGNAVOX)
A17N7UT
1EMN27760A
Ref. No. Description Part No.
LCD1# LCD PANEL ASSEMBLY U3FF2MA
Consists of the following
A1 FRONT CABINET A3AF1UT 1EM128333
A6 CONTROL PLATE A31F0UT 1EM334317
A9 SENSOR LENS A3AF0UT 1EM334258
B12 SHIELD PLATE A3AF0UT 1EM334260
CL3006 FFC WIRE ASSEMBLY 30PIN(W/SHIELD) 30P/
FFC/SHIELD/500MM
WX1A3AF0P401
L4 SCREW P-TIGHT M3X8 BIND HEAD+ BLK GBHP3080
LCD MODULE ----------
W01 WIRE ASSEMBLY 2PIN 2PIN/70MM/1PIN-
BLACK
WX1U3FF2-W01
