TYPE B
PARTS LIST [LF320FX4F (Serial No.: DS2)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Different parts from the original model
32ME303V/F7 (Serial No. : ME1)
Ref. No. Description Part No.
A4 BOTTOM COVER A3AFCUH 1EM031005
A15# RATING LABEL A3AFNUH ----------
A16 LOGO LABEL A3AU0UH ----------
A17 ENERGY GUIDE LABEL A3AFNUH ----------
SA1 STAND ASSEMBLY A21F0UH 1EM029048A
SSK1 STAND SCREW KIT A3AFCUH(SCREW P-
TIGHT M4X14 BIND HEAD+BLK)
1ESA35205
S1 CARTON A3AFNUH 2EMC00194
S6 SET BAG A21F0UH 1EM335137
X2# OWNERS MANUAL A3AFNUH 2EMN00101
X3 REMOTE CONTROL UNIT NH307UD NH307UD
X4 Not used
X6 QUICK START GUIDE A3AFNUH 2EMN00102
X7 Not used
LCD1# LCD PANEL ASSEMBLY U34F7F0
A1 FRONT CABINET A3AFNUH 2EMM00208
CL3006 FFC WIRE ASSEMBLY 30PIN(W/SHIELD)
30P/FFC/SHIELD/600MM
WX1A3AFCP411
To Next Page
