FUNAI LH8-M40BB - ELECTRICAL PARTS LIST

20100323 15-1 A03P0/P1EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DIGITAL MAIN CBA UNIT
POWER SUPPLY ASSEMBLY
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
LH8-M40BB A
LT 8 - M 40 B B B
Ref. No. Mark Description Part No.
A
B
DIGITAL MAIN CBA UNIT
DIGITAL MAIN CBA UNIT
A03P0MMA-001
A03P1MMA-001
Ref. No. Mark Description Part No.
A
B
POWER SUPPLY ASSEMBLY
POWER SUPPLY ASSEMBLY
Consists of the following:
A03P0MPW-001
A03P1MPW-001
POWER SUPPLY CBA
JACK CBA
----------
----------
Ref. No. Mark Description Part No.
POWER SUPPLY CBA
Consists of the following:
----------
CAPACITORS
C11 CHIP CERAMIC CAP. CH J 15pF/50V CHD1JJ3CH150
C12 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C16 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C18 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C19 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C20 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C22 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C24 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C27 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C28 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C31 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C33 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
C34 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
C35 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V
CHD1EK30B104
C36 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C37 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V
CHD1EK30B104
C38 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C181 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C182 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C204 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C205 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C206 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C207 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C208 A CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C209 A CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C213 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C214 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C215 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C216 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C217 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C222 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C223 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C301 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
C302 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C303 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C304 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
C305 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C306 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C307 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C308 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C309 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C310 ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C311 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C312 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
C313 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C314 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C315 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
C316 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C317 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C318 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C319 ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C320 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C323 CHIP CERAMIC CAP.(1608) B K 3300pF/
50V
CHD1JK30B332
C324 CHIP CERAMIC CAP.(1608) B K 3300pF/
50V
CHD1JK30B332
C401 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C402 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
Ref. No. Mark Description Part No.
