20100323 15-3 A03P0/P1EL
C833 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C835 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C836 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C838 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C839 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C840 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C841 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
CONNECTORS
CN101 242 SERIES CONNECTOR
224202106W1
J322C06TG001
CN401 FFC CONNECTOR IMSA-9615S-29A-PP-
A or
JC96J29ER007
CONNECTOR PRINT MES 00 6232 029
006 800+ or
JC62G29UG026
CONNECTOR PRINT MES 29 S 1.0-11-
29P
JC1129JSH001
CN402 FFC CONNECTOR IMSA-9615S-29A-PP-
A or
JC96J29ER007
CONNECTOR PRINT MES 00 6232 029
006 800+ or
JC62G29UG026
CONNECTOR PRINT MES 29 S 1.0-11-
29P
JC1129JSH001
CN403 FFC CONNECTOR IMSA-9615S-29A-PP-
A or
JC96J29ER007
CONNECTOR PRINT MES 00 6232 029
006 800+ or
JC62G29UG026
CONNECTOR PRINT MES 29 S 1.0-11-
29P
JC1129JSH001
CN404 FFC CONNECTOR IMSA-9615S-29A-PP-
A or
JC96J29ER007
CONNECTOR PRINT MES 00 6232 029
006 800+ or
JC62G29UG026
CONNECTOR PRINT MES 29 S 1.0-11-
29P
JC1129JSH001
CN452 PH CONNECTOR TOP 6P B6B-PH-K-S
(LF)(SN) or
J3PHC06JG029
CONNECTOR PRINT OSU C S 440054-6
or
J344C06AP001
CONNECTOR PRINT OSU JS-1125-
06(K)
J3JT06CHY001
CN453 FPC/FFC CONNECTOR IMSA-9615S-
07A-PP-A or
JC96J07ER007
CONNECTOR PRINT MES 07 S 1.0-11-
7P or
JC1107JSH001
CONNECTOR PRINT MES 00 6232 007
006 800+
JC62G07UG026
CN600
!
WIRE ASSEMBLY 3PIN 3PIN/70MM/
AWG18/UL10
WX1A03P0-303
CN601 CONNECTOR B2P3-VH(LF)(SN) or J3VH020JG001
CONNECTOR PRINT OSU 02/S/JS-
1120-03N02
J3JT02CHY004
CN610
!
WIRE ASSEMBLY 2PIN 2PIN/80MM/
AWG18/BLAC
WX1A03A0-302
CN801 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN) or
J3PHC02JG029
CONNECTOR PRINT OSU TOP 2P
440054-2 or
J344C02AP001
CONNECTOR PRINT OSU JS-1125-
02KK
J3JT02CHY002
CN802 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN) or
J3PHC02JG029
CONNECTOR PRINT OSU TOP 2P
440054-2 or
J344C02AP001
CONNECTOR PRINT OSU JS-1125-
02KK
J3JT02CHY002
DIODES
D183 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E or QDTZ0HSS4148
DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F
D301 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D302 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
Ref. No. Mark Description Part No.
D303 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D304 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D305 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D306 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D307 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D308 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D309 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D310 DIODE ZENER 3V9BSB-T26 or NDTB3R9BST26
DIODE ZENER HZS3.9NB2TE-EQ QDTB0HZS3R9N
D311 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D312 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D313 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D314 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D315 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D316 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D317 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D318 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D319 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D320 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D321 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D322 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D323 DIODE ZENER 3V9BSB-T26 or NDTB3R9BST26
DIODE ZENER HZS3.9NB2TE-EQ QDTB0HZS3R9N
D324 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D325 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D326 DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
DIODE ZENER HZS5.6NB2TE-EQ QDTB0HZS5R6N
D501 DIODE ZENER 13BSB-T26 or NDTB013BST26
ZENER DIODE MTZJT-7713B or QDTB00MTZJ13
DIODE ZENER DO-34 MTZJ13B or NDTB00MTZJ13
DIODE ZENER HZS13NB2TE-EQ QDTBHZS13NB2
D502 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E or QDTZ0HSS4148
DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F
D503 SCHOTTKY BARRIER DIODE SB390 NDWZ000SB390
D504 SCHOTTKY BARRIER DIODE SB390 NDWZ000SB390
D505 DIODE ZENER 18BSB-T26 or NDTB018BST26
DIODE ZENER HZS18NB2TE-EQ QDTBHZS18NB2
D508 DIODE ZENER 8V2BSA-T26 or NDTA8R2BST26
DIODE ZENER HZS8.2NB1TE-EQ QDTA0HZS8R2N
D511 SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D514 DIODE FR154 or NDLZ000FR154
DIODE FR154BD NDL1000FR154
D515 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E or QDTZ0HSS4148
DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F
Ref. No. Mark Description Part No.
