20100323 15-9 A03P0/P1EL
JACK CBA
R802 CHIP RES. 1/10W F 27k Ω or RRXAFR5H2702
CHIP RES.(1608) 1/10W F 27k Ω or RRXAFR5Z2702
RES CHIP 1608 1/10W F 27.0k Ω RTW2702YF002
R803 CHIP RES. 1/10W F 10k Ω or RRXAFR5H1002
CHIP RES. 1/10W F 10k Ω or RRXAFR5Z1002
RES CHIP 1608 1/10W F 10.0k Ω RTW1002YF002
R804 CHIP RES. 1/10W F 10k Ω or RRXAFR5H1002
CHIP RES. 1/10W F 10k Ω or RRXAFR5Z1002
RES CHIP 1608 1/10W F 10.0k Ω RTW1002YF002
R806 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R807 CHIP RES. 1/10W J 12k Ω or RRXAJR5Z0123
RES CHIP 1608 1/10W J 12k Ω RRXA123YF002
R810 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R824 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
B9 HEAT SINK PMR ASSEMBLY A8CN0FP 1EM425837A
B10 MODULE HEAT SINK PMC P7150UT 1EM423968
BC11 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC181 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
BC182 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
BC501 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC621 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC622 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC623 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC624 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC801 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
F601! FUSE 4A/250V(PB FREE) 0215004.MXP PBGZ20BAG021
FH605 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH606 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
JK201 JACK RCA PCB S GREEN 01/RCA-
101H(GN) or
JXRJ010YUQ03
JACK RCA PCB S(GREEN) 01 MTJ-032-
04B-73 FE
JXRJ010LY030
JK202 JACK RCA PCB S BLUE 01/RCA-
101H(BL) or
JXRJ010YUQ04
JACK RCA PCB S(BLUE) 01 MTJ-032-
04B-74 FE
JXRJ010LY033
JK203 JACK RCA PCB S RED 01/RCA-
101H(RD) or
JXRJ010YUQ01
JACK RCA PCB S(RED) 01 MTJ-032-
04B-75 FE
JXRJ010LY028
JK204 JACK RCA PCB S WHITE 01/RCA-
101H(WH) or
JXRJ010YUQ02
JACK RCA PCB S (WHITE) 01 MTJ-032-
04B-41 FE
JXRJ010LY031
JK205 JACK SW RCA PCB S RED RCA-
102H(RD) or
JYRJ010YUQ03
JACK SW RCA PCB S(RED) 01 MTJ-032-
04A-75 FE
JYRJ010LY031
JK206 JACK HPEP SML PCB S PJ-358H or JXSJ020YUQ01
JACK HPEP SML PCB S 02 MSJ-035-
29D (ABS)
JXSJ020LY001
JK207 A JACK RCA PCB S ORANGE 01/RCA-
101H(OR) or
JXRJ010YUQ06
AJACK RCA PCB S(ORANGE) 01 MTJ-
032-04B-76 FE
JXRJ010LY029
JK210 JACK SW DIN PCB S 04/DIN-417HA-01
or
JYEJ040YUQ03
JACK SW DIN PCB S 04 MDC-076H-A LF JYEJ040LY002
JK211 JACK RCA PCB S YELLOW 01/RCA-
101H(YL) or
JXRJ010YUQ05
JACK RCA PCB S (YELLOW) 01 MTJ-
032-04B-40 FE
JXRJ010LY032
JK212 JACK RCA PCB S WHITE 01/RCA-
101H(WH) or
JXRJ010YUQ02
JACK RCA PCB S (WHITE) 01 MTJ-032-
04B-41 FE
JXRJ010LY031
JK213 JACK SW RCA PCB S RED RCA-
102H(RD) or
JYRJ010YUQ03
Ref. No. Mark Description Part No.
JACK SW RCA PCB S(RED) 01 MTJ-032-
04A-75 FE
JYRJ010LY031
JK301 JACK RGB PCB S 01/RGB-11HS JXGJ21YUQ001
JK302 JACK RGB PCB S 01/RGB-11HS JXGJ21YUQ001
JS12 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
JS13 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
JS14 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
JS505 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
JS511 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
JS551 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
JS552 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
JS553 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
JS609 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
JS610 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
JS801 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
L3 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA602! SURGE ABSORBER 470V+-10PER or NVQZ10D471KB
! VAR ISTOR 10 D 47 1K SVR NVQZ VR1 0D47 1
SA608! SURGE ABSORBER 470V+-10PER or NVQZ10D471KB
! VAR ISTOR 10 D 47 1K SVR NVQZ VR1 0D47 1
T601! TRANS POWER BCK-35-0720 LTT3PE0XB058
T602! PFC CHOKE JCC41-0026 LLEE0Z0XB009
Ref. No. Mark Description Part No.
JACK CBA
Consists of the following:
----------
CAPACITORS
C212 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C220 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V
CHD1JK30B473
C221 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V
CHD1JK30B473
RESISTORS
R218 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R219 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
JK208 JACK SW HPEP SML PCB L PJ-350 or JYSL010YUQ03
JACK SW HPEP SML PCB L MSJ-2000
AG(B110)
JYSL010LY005
CL201A WIRE ASSEMBLY 4PIN 4PIN/120MM/
AWG26/STR
WX1A03A0-001
Ref. No. Mark Description Part No.
To Next Page
