FUNAI LT6-M19BB - Function, Jack, and MUT CBA Parts Lists; Function CBA Parts List; Jack CBA Parts List; MUT CBA Components

20090828 13-8 A8CN1_N4EL
FUNCTION CBA
JACK CBA
MUT CBA
DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D302 LED(GREEN) LTL-4234 or NPWZ0LTL4234
LED GREEN 333GT/E(FNA) NPWZ33GTEFNA
D303 LED L-53HT or NP4Z000L53HT
LED 333HT/E-L or NPHL00333HTE
LED 333HT/E-K NPHK00333HTE
RESISTORS
R301 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
R302 CHIP RES. 1/10W J 330 Ω or RRXAJR5Z0331
RES CHIP 1608 1/10W J 330 Ω RRXA331YF002
R303 CHIP RES. 1/10W J 330 Ω or RRXAJR5Z0331
RES CHIP 1608 1/10W J 330 Ω RRXA331YF002
R304 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002
R308 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
RS301 SENSOR REMOTE RECEIVER KSM-
712TH2E
USESJRSKK044
Ref. No. Mark Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITORS
C201 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C202 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
CONNECTORS
CN201 WIRE ASSEMBLY 6PIN 6PIN/250MM/
AWG26
WX1A8CN0-008
CN202 WIRE ASSEMBLY 5PIN WX1A8CN0-002 WX1A8CN0-002
DIODES
D201 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D202 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D203 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
RESISTORS
R201 CARBON RES. 1/4W G 10k Ω RCX4GATZ0103
R202 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R203 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R204 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R205 CARBON RES. 1/4W G 2.2k Ω RCX4GATZ0222
R206 CARBON RES. 1/4W G 2.7k Ω RCX4GATZ0272
R207 CARBON RES. 1/4W G 4.7k Ω RCX4GATZ0472
R208 CARBON RES. 1/4W G 6.8k Ω RCX4GATZ0682
SWITCHES
SW201 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW202 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW203 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW204 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW205 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW206 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
Ref. No. Mark Description Part No.
SW207 TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
Ref. No. Mark Description Part No.
JACK CBA
Consists of the following:
----------
CAPACITORS
C14 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
C15 CHIP CERAMIC CAP.(1608) B K 5600pF/
50V
CHD1JK30B562
CONNECTOR
CN11 CONNECTOR PRINT MES 08FMN-
STRK-A(LF)(SN)
JCFNG08JG022
RESISTORS
R11 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R12 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R13 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R14 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
R15 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
R16 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R17 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R18 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R19 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R20 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R21 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R22 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R23 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002
R24 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002
MISCELLANEOUS
JK11 JACK RCA PCB S GREEN 01/RCA-
101H(GN) or
JXRJ010YUQ03
JACK RCA PCB S(GREEN) 01 MTJ-032-
04B-73 FE
JXRJ010LY030
JK12 JACK RCA PCB S BLUE 01/RCA-
101H(BL) or
JXRJ010YUQ04
JACK RCA PCB S(BLUE) 01 MTJ-032-
04B-74 FE
JXRJ010LY033
JK13 JACK RCA PCB S RED 01/RCA-
101H(RD) or
JXRJ010YUQ01
JACK RCA PCB S(RED) 01 MTJ-032-
04B-75 FE
JXRJ010LY028
JK14 JACK RCA PCB S WHITE 01/RCA-
101H(WH) or
JXRJ010YUQ02
JACK RCA PCB S (WHITE) 01 MTJ-032-
04B-41 FE
JXRJ010LY031
JK15 JACK SW RCA PCB S RED RCA-
102H(RD) or
JYRJ010YUQ03
JACK SW RCA PCB S(RED) 01 MTJ-032-
04A-75 FE
JYRJ010LY031
Ref. No. Description Part No.
MUT CBA
Consists of the following:
A8CN0MUT-001
INVERTER CBA
JUNCTION CBA
----------
----------
Ref. No. Mark Description Part No.
