20090828 13-9 A8CN1_N4EL
INVERTER CBA
Ref. No. Description Part No.
INVERTER CBA
Consists of the following:
----------
CAPACITORS
C401 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C402 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V J
or
CA2A104DT018
CAP POLYESTER FILM 0.1µF/100V J CA2A104SER02
C404 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C405 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V J
or
CA2A104DT018
CAP POLYESTER FILM 0.1µF/100V J CA2A104SER02
C406 CAP CHIP CERAMIC 5pF/3.15KV/DJ CA3F5R0MR060
C407 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C408 CAP CHIP CERAMIC 5pF/3.15KV/DJ CA3F5R0MR060
C411 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C412 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C413 ELECTROLYTIC CAP. 1000µF/25V M or CE1EMZNDL102
ELECTROLYTIC CAP. 1000µF/25V M CE1EMZPDL102
C414 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C415 CAP METALIZED FILM 0.11µF 250V H MPEF CT2E114DT065
C416 CAP CERAMIC HV 12P 3KV SL J or CCD3FJPSL120
CAP CERAMIC-HV 12pF/3.15KV/SL/J CCD3FJASL120
C417 CAP CERAMIC HV 12P 3KV SL J or CCD3FJPSL120
CAP CERAMIC-HV 12pF/3.15KV/SL/J CCD3FJASL120
C419 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C420 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V J
or
CA2A104DT018
CAP POLYESTER FILM 0.1µF/100V J CA2A104SER02
C423 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
C450 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C451 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
CONNECTORS
CN401 CONNECTOR PRINT OSU KW04-800-0200 J30402KET001
CN402 CONNECTOR PRINT OSU KW04-800-0200 J30402KET001
CN451 CONNECTOR PRINT OSU 008283021200000S+
or
J383C02UG004
CONNECTOR PRINT OSU 2P 292161-2 J31FC02AP001
DIODES
D402 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D403 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D405 ZENER DIODE MTZJT-7715B or QDTB00MTZJ15
DIODE ZENER 15BSB-T26 NDTB015BST26
D408 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D409 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D410 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D411 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D412 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D413 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D414 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D415 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D416 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D418 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D419 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D422 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D423 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D425 PCB JUMPER D0.6-P5.0 JW5.0T
D428 ZENER DIODE MTZJT-775.1B or QDTB0MTZJ5R1
DIODE ZENER 5V1BSB-T26 NDTB5R1BST26
COILS
L401B POWER INDUCTER RCR1616-471K or LLC471KSF009
COIL RADIAL LH L 13NB471K 470µH LLF4710TU012
L403 CHOKE COIL 22µH-K or LLBD00PKV021
CHOKE COIL 22µH-K or LLBD00PU6011
CHOKE COIL 22µH-K LLBD00PKT002
TRANSISTORS
Q401 TRANSISTOR 2SA950-O (TE2 F T) or QQS002SA950F
TRANSISTOR 2SA950-Y(TE2 F T) or QQSY02SA950F
TRANSISTOR (PB FREE) KTA1271-Y-AT/P or NQSYKTA1271P
PNP TRANSISTOR 2SA1981Y-AT NQSY02SA1981
Q402 TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P or NQS4KTC3198P
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
NPN TRANSISTOR 2SC5343G-AT or NQSG02SC5343
NPN TRANSISTOR 2SC5343MG-AT NQSG2SC5343M
Q403 TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P or NQS4KTC3198P
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
NPN TRANSISTOR 2SC5343G-AT or NQSG02SC5343
NPN TRANSISTOR 2SC5343MG-AT NQSG2SC5343M
Q404 TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P
TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-Y(TE2 F T) or QQSY2SA1015F
TRANSISTOR 2SA1015-GR(TE2 F T) or QQS12SA1015F
PNP TRANSISTOR 2SA1980 G or NQSG02SA1980
PNP TRANSISTOR 2SA1980MG-AT NQSG2SA1980M
Q405 TRANSISTOR 2SC2120-O(TE2 F T) or QQS02SC2120F
TRANSISTOR 2SC2120-Y(TE2 F T) or QQSY2SC2120F
TRANSISTOR KTC3203-Y-AT/P or NQSYKTC3203P
NPN TRANSISTOR 2SC5344 Y NQSY02SC5344
Q406 NPN TRANSISTOR POWER 2SC4881F HFE
MAX320
QQWZ2SC4881F
Q407 TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P or NQS4KTC3198P
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
NPN TRANSISTOR 2SC5343G-AT or NQSG02SC5343
NPN TRANSISTOR 2SC5343MG-AT NQSG2SC5343M
Q408! FET MOS SMD HAT2215R01-EL-E QF2ZHAT2215R
Q410 TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P or NQS4KTC3198P
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
NPN TRANSISTOR 2SC5343G-AT or NQSG02SC5343
NPN TRANSISTOR 2SC5343MG-AT NQSG2SC5343M
Q411 TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P
TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-Y(TE2 F T) or QQSY2SA1015F
TRANSISTOR 2SA1015-GR(TE2 F T) or QQS12SA1015F
PNP TRANSISTOR 2SA1980 G or NQSG02SA1980
PNP TRANSISTOR 2SA1980MG-AT NQSG2SA1980M
Q412 TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P or NQS4KTC3198P
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
NPN TRANSISTOR 2SC5343G-AT or NQSG02SC5343
NPN TRANSISTOR 2SC5343MG-AT NQSG2SC5343M
Q413 TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR KTC3198-GR-AT/P or NQS4KTC3198P
TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F
NPN TRANSISTOR 2SC5343G-AT or NQSG02SC5343
NPN TRANSISTOR 2SC5343MG-AT NQSG2SC5343M
Ref. No. Description Part No.
