FUNAI LT6-M19BB - Resistor and Junction CBA Parts Lists; Resistors (R401-R447); Resistors (R454-R457); Junction CBA Parts List

20090828 13-10 A8CN1_N4EL
JUNCTION CBA
RESISTORS
R401 CHIP RES. 1/10W J 1.5k Ω or RRXAJR5Z0152
RES CHIP 1608 1/10W J 1.5k Ω RRXA152YF002
R402 CARBON RES. 1/4W J 27k Ω RCX4JATZ0273
R404 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002
R405 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R406 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R407 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R408 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R409 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R410 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R411 CHIP RES. 1/10W J 3.3k Ω or RRXAJR5Z0332
RES CHIP 1608 1/10W J 3.3k Ω RRXA332YF002
R412 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R413 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R414 CHIP RES. 1/10W J 47 Ω or RRXAJR5Z0470
RES CHIP 1608 1/10W J 47 Ω RRXA470YF002
R415 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R417 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R418 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R419 CHIP RES. 1/10W J 330 Ω or RRXAJR5Z0331
RES CHIP 1608 1/10W J 330 Ω RRXA331YF002
R420 CHIP RES. 1/10W J 8.2k Ω or RRXAJR5Z0822
RES CHIP 1608 1/10W J 8.2k Ω RRXA822YF002
R422 CHIP RES. 1/10W J 820k Ω or RRXAJR5Z0824
RES CHIP 1608 1/10W J 820k Ω RRXA824YF002
R423 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002
R424 CHIP RES. 1/10W J 9.1k Ω or RRXAJR5Z0912
RES CHIP 1608 1/10W J 9.1k Ω RRXA912YF002
R425 CHIP RES. 1/10W J 56 Ω or RRXAJR5Z0560
RES CHIP 1608 1/10W J 56 Ω RRXA560YF002
R426 CHIP RES. 1/10W J 56 Ω or RRXAJR5Z0560
RES CHIP 1608 1/10W J 56 Ω RRXA560YF002
R427 CHIP RES. 1/10W J 560k Ω or RRXAJR5Z0564
RES CHIP 1608 1/10W J 560k Ω RRXA564YF002
R428 CHIP RES. 1/10W J 560k Ω or RRXAJR5Z0564
RES CHIP 1608 1/10W J 560k Ω RRXA564YF002
R429 CHIP RES. 1/10W J 820k Ω or RRXAJR5Z0824
RES CHIP 1608 1/10W J 820k Ω RRXA824YF002
R430 CARBON RES. 1/4W J 3.3 Ω RCX4JATZ03R3
R431 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002
R432 CHIP RES. 1/10W J 820 Ω or RRXAJR5Z0821
RES CHIP 1608 1/10W J 820 Ω RRXA821YF002
R435 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R436 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R437 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R438 CHIP RES. 1/10W J 560 Ω or RRXAJR5Z0561
RES CHIP 1608 1/10W J 560 Ω RRXA561YF002
R439 METAL OXIDE FILM RES. 2W J 0.68 Ω or RN02R68ZU001
METAL OXIDE FILM RES. 2W J 0.68 Ω RN02R68DP004
R440 CHIP RES. 1/10W J 100k Ω or RRXAJR5Z0104
RES CHIP 1608 1/10W J 100k Ω RRXA104YF002
R441 CHIP RES. 1/10W J 130k Ω or RRXAJR5Z0134
RES CHIP 1608 1/10W J 130k Ω RRXA134YF002
R442 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002
R446 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R447 CHIP RES. 1/10W J 220k Ω or RRXAJR5Z0224
RES CHIP 1608 1/10W J 220k Ω RRXA224YF002
Ref. No. Description Part No.
R454 METAL OXIDE FILM RES. 2W J 0.33 Ω or RN02R33ZU001
METAL OXIDE FILM RES. 2W J 0.33 Ω RN02R33DP004
R455 CHIP RES. 1/10W J 22k Ω or RRXAJR5Z0223
RES CHIP 1608 1/10W J 22k Ω RRXA223YF002
R456 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R457 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
JS402 PCB JUMPER D0.6-P5.0 JW5.0T
JS411 PCB JUMPER D0.6-P5.0 JW5.0T
T401! TRANS INVERTER ETJV26ZE11AC LTZ3PC0MS001
Ref. No. Description Part No.
JUNCTION CBA
Consists of the following:
----------
CONNECTOR
CN403A WIRE ASSEMBLY 12PIN WX1A8CN0-101 WX1A8CN0-101
MISCELLANEOUS
CL403 242 SERIES CONNECTOR TUC-P12X-B1 WHT
ST
JCTUB12TG002
Ref. No. Description Part No.
TU501! TUNER UNIT DTV ENG37E06KF UTUNDVTMS002
Ref. No. Description Part No.
