FUNAI LT850-M26 - Mechanical Parts List

20100518 14-1 A0CA0CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
STAND ASSEMBLY A0CA0EZ 1ESA24514
A1 FRONT CABINET A03A0EP 1EM024625
A2 CONTROL PLATE A91F0UH 1EM325799
A3 DECORATION PLATE A0CA0EP 1EM124813
A4 REAR CABINET A0CA0EP 1EM025385
A6 JACK HOLDER(HP-SW) A03A1EP 1EM326897
A10 POP LABEL A0CN0EP ----------
A11 JACK HOLDER A93F0FP 1EM123494A
B1 SHIELD BOX A0CA0EP 1EM224103
B2 TUNER SHIELD A0CA0EP 1EM327757
B3 STAND HOLDER 26W A01A1UH 1EM223865
B4 WALL MOUNT BRACKET A84N0UH 1EM323797
B5 SPEAKER HOLDER (L) A94F0UH 1EM123233
B6 SPEAKER HOLDER (R) A94F0UH 1EM123234
B13 SEPARATION SHEET(S) A0CA0EP 1EM327758
B14 SEPARATION SHEET(P) A0CA0EP 1EM327861
B16 GASKET A8AF0UH 1EM425861
B17 GASKET(4X15XT3.0) A0CN0EP 1EM431762
B18 CLOTH(10X180XT0.5) L0336JG 0EM408827
B20 SWITCH HOLDER A0CA0EP 1EM327557
B30 RUBBER CUSHION A72N0JH 1EM425197
B44 THERMOSTAR TMS-L-2(12*12HC) XK10000X4003
CL401 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL402 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL403 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL404 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL406 WIRE ASSEMBLY 11PIN FFC 11PIN 90MM WX1A9170-107
CL801 WIRE ASSEMBLY 2PIN 2PIN 160MM AWG24 R
B
WX1A0CA0-307
CL802 WIRE ASSEMBLY 2PIN 2PIN 425MM AWG24 R
B
WX1A0CA0-308
CL3901 WIRE ASSEMBLY 24PIN FFC 24PIN 80MM WX1A9170-101
L2 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L4 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L5 DOUBLE SEMS SCREW M4X6 M4X6 FPJ34060
L6 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392B
L9 HEX SCREW #4-40 7MM 1EM430139
L14 SCREW P-TIGHT M3X8 BIND HEAD+ BLK GBHP3080
LCD1 LCD MODULE CMO 6BIT NORMALGRADE UJ26MXA
SP801 SPEAKER MAGNETIC S0412F08 or DSD1609XQ001
SPEAKER MAGNETIC YDP411-17FN DS1610EFU001
SP802 SPEAKER MAGNETIC S0412F08 or DSD1609XQ001
SPEAKER MAGNETIC YDP411-17FN DS1610EFU001
PACKING
S5 SET BAG L0301UB 1EM320014B
S7 STAND BAG A71FCUH 1EM425338
ACCESSORY
X3 REMOTE CONTROL NH201RD NH201RD
Ref. No. Description Part No.
A8! RATING LABEL A0CA0EP ----------
L1 SCREW P-TIGHT M4X14 BIND HEAD+BLK GBHP4140
L2 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L6 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392B
L8 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
L10 SCREW S-TIGHT 3X8 WASHER HEAD+BLAC GCHS3080
L17 STAND SCREW KIT A0CA0EP 1ESA24768
PACKING
S1 CARTON A0CA0EP 1EM431338
S2 STYROFOAM TOP A0CA0EP 1EM026125
S3 STYROFOAM BOTTOM A0CA0EP 1EM026126
S6 SERIAL NO. LABEL L9750UA ----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2-1! OWNERS MANUAL(WE-10) A0CF0EP 1EMN25879
X2-2! OWNERS MANUAL(PL-7) A0CF0EP 1EMN25880
X4 BATTERY DRY R03REL/2PA XB00M00MS001
