bintec User’s Guide Quick Install Guide
Configuration
You can carry out the configuration in either Quick Mode or Advanced Mode. If
you are unfamiliar with networking technologies, choose Quick Mode. Your
gateway is ready for operation when you have completed the configuration.
You can select from the following configuration items:
■ basic configuration
■ Internet access
■ corporate network connection (LAN-LAN connection).
The basic configuration is essential if your gateway is still in the ex works state,
as it integrates the gateway into your local network.
Proceed as follows:
1. Select the desired items and follow the instructions on the screen.
2. To be able to use your gateway in your local network, it may be necessary
to make a few more settings on the PCs connected in the network.
You can set up Internet access over your gateway for all PCs in the same
network as your gateway. To do this, you should configure all PCs as
DHCP clients. Otherwise you must assign a fix IP address to each PC and
define your gateway as default gateway and as DNS server (see “Enter
gateway IP address at PC” on page 14).
The configuration of the gateway and its integration into your network are now
completed.
WLAN The WLAN configuration is carried out via the Setup Tool (only R230aw and
R232bw).
Further gateway
access options
The predefined IP configuration (192.168.0.254/255.255.255.0) of your gate-
way enables simple access to further configuration options.
Enter 192.168.0.254/wizard to start the HTML configuration assistant (HTML
Wizard) with any current Web browser (java script must be activated).
The HTML Setup Tool can also be opened with any current Web browser (java
script must be activated). Enter 192.168.0.254/setup to start a Setup Tool ses-
sion.
