Funkwerk bintec R230aw Technical Data

Technical Data bintec User’s Guide 9
1
Pin Assignments
Only the inner pins are used for the ADSL connection:
Figure 1-5: ADSL interface (RJ11)
The ADSL interface has the following pin assignment:
Table 1-5: ADSL interface (RJ11 socket)
Pin Function
1 Not used
2 a
3 b
4 Not used

Funkwerk bintec R230aw Specifications

General

Brand	Funkwerk
Model	bintec R230aw
Category	Gateway
Language	English
