Connections
Table 2-2: LED status display
2.4 Connections
All connections are located on the rear of the gateway. bintec R230aw of-
fers a 4-port Ethernet switch, an ADSL interface as well as a serial inter-
face.
The connections are arranged as follows:
Figure 2-2: bintec R230aw rear
ADSL on ADSL connection is active.
1. Reset Reset Button
2.
POWER
Socket for power sup-
ply
6. ADSL ADSL interface
3.
CON-
SOLE
Serial interface 8. RSMA connection
4.
4/3/2/1
10/100 Base-T Ether-
net interface
