Funkwerk bintec R230aw Technical Data

36 bintec User’s Guide Technical Data
4
bintec R232bw
Only the inner pins are used for the ADSL connection:
Figure 4-5: ADSL interface (RJ11)
The ADSL interface has the following pin assignment:
Table 4-5: ADSL interface (RJ11 socket)
4.5.4 ISDN Basic Rate Interface
bintec R232bw provides an ISDN S
0
interface, which can be used, e.g., for
backup purposes.
A RJ45 socket is used for connecting:
Figure 4-6: ISDN S
0
interface (RJ45 socket)
Pin Function
1 Not used
2 a
3 b
4 Not used
1 . . . . . 8

Funkwerk bintec R230aw Specifications

General

Brand	Funkwerk
Model	bintec R230aw
Category	Gateway
Language	English
