Pin Assignments
1.5 Pin Assignments
1.5.1 Serial Interface
For connecting a console bintec R230a provides a serial interface. Baud
rates between 1200 and 115200 Bit/s are supported.
The interface is connected through a 5-pole MiniUSB socket:
Figure 1-3: 5-pole MiniUSB socket
The pin assignment of the socket is as follows:
Table 1-3: Pin assignment of the serial socket
1.5.2 Ethernet Interface
bintec R230a offers an Ethernet interface with integrated 4-port switch for
LAN connection. It can be used to connect single PCs as well as addition-
al switches.
Pin Function
1 not used
2 Rx
3 GND
4 not used
5 Tx
