ASSEMBLY INSTRUCTIONS - DELTA RINGS
1
CHECK INVENTORY - (not to scale)
Check that you have the following
items before assembling your
Funky Monkey Bars® Delta rings.
600
600
600
4x
+ 360
o
4x
Swing Hook
4x
Carabiner
Shackle
4x
Hanging
Strap
4x
Delta Ring
4x
D - Shackle
4x
Swing Hook
Fully tighten all fitting grub screws and swing hook bolts.
2
INSTALL SWING HOOKS AND TIGHTEN BOLTS
1. If swing hooks are not already positioned
on an accessories bar attach now.
2. Loosen any neccessary fittings and slide
swing hooks onto tube into desired equally
spaced position.
3. Fully retighten any loosened fittings
4. Fully tighten swing hook bolts.
FAILURE TO DO SO COULD RESULT
IN SERIOUS INJURY OR DEATH.
NOTE : Hanging straps will deteriorate
in sunlight - Please check regularly
for fraying or any sign of deteriation.
