APPX. 1 MENU TREE
1
(Continued on next page)
(Continued from previous page)
9 INITIAL SETTINGS 2 BRILL 2 ECHO COLOR (
YEL
, GRN, WHT, AMB*
1
, M-GRN*
1
, M-CYA*
1
)
4 CONTROL PANEL (Slide-bar)
5 CHARACTERS (Slide-bar)
6 CURSOR (Slide-bar)
7 ECHOES (Slide-bar)
8 TRAILS (Slide-bar)
9 HL (Slide-bar)
4 EBL (Slide-bar)
2 RANGE RINGS (Slide-bar)
3 BEARING CURSOR (Slide-bar)
5 VRM (Slide-bar)
6 PI LINES (Slide-bar)
7 TT SYMBOLS (Slide-bar)
8 AIS SYMBOLS (Slide-bar)
9 L/L GRID (Slide-bar)
Next page
Next page
2 MARKS (Slide-bar)
3 CHART (Slide-bar)*
4
3 PALETTE (
DAY-GRY
, DAY-BLU, DAY-GRN, DUSK-GRY,
DUSK-BLU, DUSK-GRN, NIGHT-GRY, NIGHT-BLU)
Next page
2
3 4
9 SAVE INTER-SWITCH (
NO
, YES)
0 CLEAR INTER-SWITCH (NO, YES)
2 DISP1 ANTx*
2
(
MASTER
, SLAVE)
3 DISP2 ANTx*
2
(
MASTER
, SLAVE)
4 DISP3 ANTx*
2
(
MASTER
, SLAVE)
5 DISP4 ANTx*
2
(
MASTER
, SLAVE)
2 PILOT SETTING (
NO
, YES)
3 USER 1 SAVE (NO, YES)
4 USER 1 LOAD (NO, YES)
5 USER 2 SAVE (NO, YES)
6 USER 2 LOAD (NO, YES)
3 SELECT ANTENNA
*
5
4 USER SETTINGS
5 OPERATION 2 MOUSE WHEEL DIR (
NORMAL
, REVERSE)
3 KEY BEEP (OFF,
LOW
, MID, HIGH)
4 OWN SHIP VECTOR (OFF, HDG, COURSE)
5 STERN UP RM (OFF, ON)*
3
6 SHUTTLE FERRY (OFF, MODE1, MODE2)
7 ICING PREVENTION (OFF, ON)
8 BRG FINE ADJUST (-9.9º to +9.9º;
+0.0º
)
9 USB MOUSE SPEED (1, 2, 3, 4, 5)
2 AUTO COURSE UP RESET (OFF, ON)
3 DISPLAY SCROLL (OFF, ON)
*
1
(Details for the antennas currently
in use are displayed here)
2 F1 2 ECHO 2 (
CUSTOM SELECT,
IR
, ES, EAV,
NOISE REJ, ANT SELECT, PULSE
LENGTH, AUTO-SEA, AUTO-RAIN,
TUNE SELECT, 2ND ECHO REJ,
STC CURVE, STC RANGE, PM,
SART, ECHO TRAIL, TRAIL T/R,
WIPER*
1
, ACE, ACE HIGH
SENSITIVITY
)
6 FUNCTION
KEY SETUP
*
1
: Shown for B/W-type only.
*
2
: “x” indicates antenna number
(assigned at installation).
*
3
: Shown for A/B/W-types only.
*
4
: Shown for A/B/W-types with
Radar Plotter functionality only.
*
5
: For radars with Dual Radar mode
enabled, the indications show
which displays are combined.
To Next Page
