15
How to att
ach wires to the W
AGO connector
Procedure
1. T
wist the cores.
2. Press the terminal opener downward.
3. Insert the wire to hole.
4. Remove the terminal opener
.
5. Pull the wire to confirm that it is secure.
T
erminal opener
Wiring for W
AGO connector
W
AGO connector
Wire
T
wist
Press downward.
Fabrication of power cable DPYC-2.5
40 mm: Peel paint.
Taping
Armor
50 mm
6 to7 mm
Vinyl sheath
Clamp here by cable clamp.
20
22
