Digital Display Models - 1000W, 1500W, 2000W
and 3000W
1. AC Outlets — Receptacles for 115V AC products with a total
continuous power equal to the wattage (W) of your inverter.
2. Digital Readout — It indicates the power and DC voltages. The
allowed power tolerance is 15% (with loads of over 200W), and the
allowed voltage tolerance is +/-0.2V (no load).
3. Power Button — Connect the inverter to the DC power and press
down the button power switch to activate the inverter.
4. Port for Remote Starter Switch — Connect optional remote starter
switch and press power button to activate inverter.
5. USB Port — 5V/DC (500ma) power to USB equipment.
6. Red LED Indicator — When the inverter has shut down because of
low or high input voltage, the red LED indicator lights.
TO RESET: Unplug the appliance from the inverter. When thermal
shutdown problem occurs, the inverter will reset and turn back on
automatically after it cools.
7. Yellow LED Indicator
(1,000W Unit Only) — When the power exceeds
1000W, the yellow LED indicator lights. When AC output power
exceeds 1200W+/-100W, over-current protection function will act.
8. Green LED Indicator — When there is DC power input, the green
LED indicator lights
9. Positive DC Terminal — Connect the red end of the DC power cord
to it. (Cord Sold Separately)
10. Negative DC Terminal — Connect the black end of the DC power
cord to it. (Cord Sold Separately)
11. Cooling Fan and Ventilation Openings — The high speed cooling
fan protects the inverter from over-heating. IMPORTANT: VENTILATION
OPENINGS MUST REMAIN CLEAR WITH NO OBSTRUCTIONS.
12. Ground Terminal —
For grounding the power inverter chassis.
