8
FEATURES
LED INDICATOR MODELS - 80W, 400W, 750W
DC INPUT PLUG 80W
1a. 12V DC Plug - Plugs into vehicle 12V DC port
1b. Green LED - Indicates the inverter is receiving 12V power
DC INPUT PANEL 400W, 750W
1. Black Terminal - Negative DC power flow
2. Cooling Fan and Ventilation Openings - Protects the inverter
from over-heating.
3. Red Terminal - Positive DC power flow
1a
1b
1
2 3
