Fusion 782-1730 - Wiring and Digital Display Model Features; DC Cable Wiring and Digital Display Features

10
WIRING 400W, 750W
10. DC Cable with Clips— (Included with 400W and 750W
models). Connect the red clip to the positive terminal of the
battery and the black to the negative.
10
1
9 10
8 7
32 4
6 511
12
Digital Display Models - 1000W, 1500W, 2000W and 3000W
