2 Getting to know your Gator
The four main components of the Automatic Butt Fusion Machine:
2.1 Controller
The controller keypad is located under the protective cover of the control unit lid.
Display
Close button
Down button
Start or enter
button
Right button
Alarm warning
light
BlueBox LED’s
Input voltage
warning light
Up button
Return button
Left button
Open button
Chassis
Automatic
Control Unit
Trimmer
Heater
