Port Identification
Item Description
FUSE Contains the 15 A fuse for the device.
Not used.
Connects the stereo to the auxiliary in and zone 1 line/subwoofer out wiring harness.
Connects the stereo to a typical AM/FM antenna using a Motorola type antenna connector.
If you are installing the stereo on a boat with a metal hull, you must use a ground-dependent antenna,
and if you are installing the stereo on a boat with a non-metal hull, you must use a ground-independent
antenna. See the installation instructions provided with your antenna for more information.
Connects the stereo to the power and speaker wiring harness.
4 Fusion MS-RA60 Installation Instructions
