Stereo Information
Specifications
General
Weight 316g (11.2 oz)
Water resistance IEC 60529 IPX7 (front), IEC 60529 IPX5 (rear)
1
Operating temperature range From 0 to 50°C (from 32 to 122°F)
Storage temperature range From -20 to 70°C (from -4 to 158°F)
Input voltage From 10.8 to 16 Vdc
Current (max.) 15 A
Current (muted) less than 190 mA
ANT
®
wireless range Up to 3 m (10 ft.)
Compass-safe distance 15 cm (5.9 in.)
Fuse 15 A mini-blade type
Bluetooth
®
wireless range Up to 10 m (30 ft.)
Wireless frequencies/protocols Bluetooth 2.4 Ghz at 12 dBm maximum ANT 2.4 GHz @ 7 dBm maximum
On-board, Class D Amplifier
Output power per channel 4 x 22 W RMS at 14.4 Vdc input, 4 Ohm, 10% THD
2
Total output music power 4 x 45 W max. 4 Ohm. 180 W max.
Line output level (max.) 5.5 V (peak to peak)
Aux input level (typical) 1 V RMS
Tuner Europe and Australasia USA Japan
FM radio frequency range 87.5 to 108 MHz 87.5 to 107.9 MHz 76 to 95 MHz
FM frequency step 50 kHz 200 kHz 50 kHz
AM radio frequency range 522 to 1620 kHz 530 to 1710 kHz 522 to 1620 kHz
AM frequency step 9 kHz 10 kHz 9 kHz
1
From the front, the device withstands immersion in water of up to 1 m for up to 30 m. From the rear, the device withstands light jets of water (up to 30 kPa
(4.4 psi) at distance of 3 meters) for up to 3 min.
2
The stereo may limit the output power to prevent the amplifier from overheating, and to maintain the audio dynamics.
8 Fusion MS-RA60 Installation Instructions
