Fusion NV–SW12 User Manual

555
SUBWOOFER THEILE/SMALL PARAMETERS
Subwoofer Parameters NV-SW12 NV-SW15
MAX Power Rating (Watts) 2000 2500
RMS Power Rating (Watts) 1000 1100
Coil Height (Hvc) (mm) 40 40
Compliance (Cms) (uM/N) 180.8 146.18
Cone Area (Sd) 47.92 77.93
D.C.Coil Resistance (Re) 0.94 0.88
Electrical Q (Qes) 0.47 0.552
Force Factor (BL)
8.53
8.4
Free Air Resonance (Fs)
26.38 23.62
Frequency Response (Hz)
21Hz – 500Hz
19Hz – 500Hz
Gap Height (Hag) (mm)
10 10
Impedance (Nominal)
1 1
Inductance (Le) (mH)
0.5 0.51
Linear Excursion (X-Max Total)
40 40
Mechanical Excursion
15 15
Mechanical Q (Qms)
6.42
6.17
Moving Mass (Mms)
219.88 285.85
Sensitivity (dB)
85 87
Total Loudspeaker Q (Qts)
0.44 0.506
VAS (Litres)
52.21 126.07
VAS (CuFt)
1.845 4.45
Magnet Structure (Oz)
308 308
Total Loudspeaker Displacement (Litres)
8 12

Fusion NV–SW12 Specifications

General

Brand	Fusion
Model	NV–SW12
Category	Subwoofer
Language	English
