Fusion NV–SW12 User Manual

888
ENCLOSURES
All enclosures include port and subwoofer displacement. All ports are circle aero ports unless
otherwise stated.
Ported Enclosures: A ported enclosure is generally larger than a sealed enclosure
Sealed Enclosures: A sealed enclosure will be the smallest enclosure you can build. It will have a
tight low frequency response, but not as low as a ported enclosure.
OPTIMUM ENCLOSURES
PORTED NV-SW12 NV-SW15
Volume (litres) 87.38 106.4
Volume (cu.ft) 3.086 3.759
Port diameter (mm / in) 101mm / 4" 101mm / 4"
Port length (mm / in) 304mm / 11-15/16" 289mm / 11-3/8"
Tuned frequency (Hz) 28 26.2
SEALED
Volume (litres) 55.62 75.7
Volume (cu.ft) 2.043 2.68
Tuned frequency (Hz) 45 37

Fusion NV–SW12 Specifications

General

Brand	Fusion
Model	NV–SW12
Category	Subwoofer
Language	English
