Fusion PF-4001D

22
Version 2.1
PF-1802 (2 Channel) PF-4004 (4 Channel)
Class Class-AB Class-AB
Power 1200 Watts 2400 Watts
Frequency Response 20Hz - 20kHz 20Hz - 20kHz
Dimensions 246mm (9-11/16”) x 200mm
(7-7/8”) x 51mm (2”)
386mm (15-3/16”) x 200mm
(7-7/8”) x 51mm (2”)
RMS Power Ratings 65W x 2 @ 4 Ohms 1% THD+N
90W x 2 @ 2 Ohms 1% THD+N
180W x 1 @ 4 Ohms Bridged 1%
THD+N
80W x 4 @ 4 Ohms 1% THD+N
100W x 4 @ 2 Ohms 1% THD+N
200W x 2 @ 4 Ohms Bridged 1%
THD+N
Signal to Noise Ratio >50 dB >50 dB
High and Low Pass
Crossover
12dB per Octave 12dB per Octave
Bass Boost @ 45Hz 0 - +18dB N/A
Crossover Range 50Hz – 400Hz 50Hz – 400Hz
Low Level Input Range 0.35 Volts to 10 Volts 0.35 Volts to 10 Volts
High Level Input Range 1 Volt to 30 Volts 1 Volt to 30 Volts
Minimum load
impedance
2 Ohm stereo and 4 Ohm bridged 2 Ohm stereo and 4 Ohm bridged
PF-4001D (Monoblock) PF-8001D (Monoblock) PF-8003D (3 Channel)
Class Class-D Class-D Class-D
Power 1600 Watts 3200 Watts 2400 Watts
Frequency Response 10Hz - 250Hz 10Hz - 250Hz 10Hz - 20kHz
Dimensions 236mm (9-1/4”) x 200mm (7-
7/8”) x 51mm (2”)
306mm (12”) x 200mm (7-7/8”) x
51mm (2”)
306mm (12”) x 200mm (7-7/8”) x
51mm (2”)
RMS Power Ratings 250W x 1 @ 4 Ohms 1% THD
400W x 1 @ 2 Ohms 1% THD
500W x 1 @ 4 Ohms 1% THD
800W x 1 @ 2 Ohms 1% THD
Link Mode (Two PF-8001D)
1600W x 1 @ 4 Ohms 1% THD
Front 90W x 2 @ 4 Ohms
150W x 2 @ 2 Ohms 1% THD+N
Sub 230W x 1 @ 4 Ohms
500W x 1 @ 2 Ohms 1% THD+N
Signal to Noise Ratio >50 dB >50 dB >50 dB
High and Low Pass
Crossover
12dB per Octave 12dB per Octave 12dB per Octave
Subsonic Filter 12dB per Octave 12dB per Octave 12dB per Octave
Low Pass Crossover
Range
50Hz – 250Hz 50Hz – 250Hz 50Hz – 250Hz
Subsonic Crossover
Range
10Hz – 40Hz 10Hz – 40Hz 10Hz – 40Hz
Bass Boost @ 45Hz 0 to +18dB 0 to +18dB 0 to +18dB
Low Level Input Range 0.35 Volts to 10 Volts 0.35 Volts to 10 Volts 0.35 Volts to 10 Volts
High Level Input Range 1 Volt to 30 Volts 1 Volt to 30 Volts 1 Volt to 30 Volts
Minimum load
impedance
2 Ohm 2 Ohm and 4 Ohm in Link mode 2 Ohm
AMPLIFIER SPECIFICATIONS
NOTE:
PERFORMANCE
AMPLIFIER SERIES
HAVE A MINIMUM
LOAD IMPEDANCE
OF
2 OHM PER
CHANNEL
4 OHM BRIDGED
General
Power
Requirements
+12 V DC
(negative
ground)
Operating
Voltage
10.5 – 16V
Minimum
Recommended-
Power/Ground
Cable Size
4 Gauge (AWG)
Recommended
inline fuse size
4 Gauge Cable
- 80A
ENGLISH
