Receiver R127DF/R147F
"7": Not Used (CH7)
"6": Flap servo (CH6)
"5": Gear servo (CH5)
"4": Rudder servo (CH4)
"3": Throttle servo (CH3)
"2": Elevator servo (CH2)
"1": Aileron servo (CH1)
"B" Battery Connector
Crystal: The crystal is installed at the side of the receiver.
Servo S3003
Accessories: The following items are supplied with the set:
-Spare servo horns: Use to match the application.
-Servo mounting parts: Rubber grommets, etc.
-13-
Antenna
Mounting flange
Servo wheel
Crystal
To receiver
