4. After setting the push rod at each servo, operate each servo fully left and right at least once. If the rod catches
or sticks at this time, the servo has been damaged by an overcurrent. Therefore verify that the rods are
functioning perfectly.
5. Be especially careful of noise signals. For instance, noise signals will be generated by the contact of metal
against metal due to engine vibration. If these noise signals are received at the receiver, the receiver may operate
erroneously. Therefore cover one of the metal surfaces with insulating material.
6. After installation is complete, ask a nearby radio control expert or the dealer where the equipment was purchased
to instruct you on the proper handling techniques and other items which may require special attention. Also
have your installation thoroughly checked at this time.
Strict observance of safety rules and adherence to the advise of experts will make radio control more enjoyable.
FUTABA PROPORTIONAL FREQUENCIES
(Available in MHz. Available Futaba pair crystal Tx/Rx)
27 MHz Areas
26.995 (Brown)
27.045
(Red)
27.095 (Orange)
27.145 (Yellow)
27.195 (Green)
72 MHz Areas
72.080 (Brown/White)
72.160 (Blue/White)
72.240 (Red/White)
72.320 (Violet/White)
72.400 (Orange/White)
72.960 (Yellow/White)
75.640 (Green/White)
Remarks: Mark * Model Aircraft use only.
