FUTABA FP-8JN - Page 13

No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Details
Upper case
Middle case
Bottom case
Pinion motor
1 st gear
2nd gear
3rd gear
Final gear
2nd shaft
Intermediate
shaft
Output shaft
Spacer washer
Seal ring
Radial ball
bearing
Pan head screw
Truss screw
Motor
Slider
Volume
Grommet
Name plate
Fiber washer
Servo horn
Toothed washer
Phillips pan
head screw
E ring
0 ring
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
2
4
2
1
1
1
1
1
2
1
1
1
Remarks
M2x24
M2x5
16
M2
M2x5
Fig. 11
