26
DATA SETTING
When Using a T8Usuper Transmitter
The Gyro Mixing (GYRO) function lets operator perform a gain adjustment at
each Idle-Up switch position.
[GY502 Settings]
Select the gyro operation mode at the GY502 Mode screen. (AVC, NOR, or
CMT)
[Transmitter Settings]
Gyro Mixing function:
1. Select the “ON” mode at the transmitter Gyro Mixing (GYRO) setup
screen.
2. Select the Idle-Up switch(SW-E) for the sensitivity selection.
3. Set the “NORM”, “IDL1” and “IDL2” gains.
(The following page shows a setting example in the CMT mode.)
[Sensitivity Display]
The gain display indicates the actual gain at the GY502 normal screen
display.
The following shows the relationship between transmitter and gyro setting
when GY502 sensitivity setting is 100% in both the G1 and G2 gain modes.
- Relationship between transmitter and gyro setting
Transmitter
settings
GY502mode
settings
Actual gain
NORM
IDL1
IDL2
NOR
AVC
CMT
0% - 50% - 100%
Normal mode
AVCS mode
Normal mode AVCS mode
(G2) (G1)
100% - 0% - 100%
